1
Engine displacement
300
2
Model
BEVERLY
3
Year
2015
4
Trim
BEVERLY RST/S 4T 4V IE E3
5
Parts Catalog
Crankcase cover - Crankcase cooling
6
Parts Diagram
Parts Catalog
Silencer
by
Driving mirror/s
Crankcase cover - Crankcase cooling
1
2
3
4
5
6
7
8
8
9
10
11
12
13
14
15
16
17
1
Complete transmission cover
8778435
Not Available
2
Pin 6,5x9,5x15
239388
Not Available
3
Snap ring
006635
$0,25 Unit Price incl. VAT
4
Radial bearing 15x35x11
4789853
$6,05 Unit Price incl. VAT
5
Screw w/ flange M6x30
B016792
$0,25 Unit Price incl. VAT
5
Screw w/ flange M6x30
289731
Not Available
6
Cooling Cover
876075
Not Available
7
screw M6x25
018553
$0,25 Unit Price incl. VAT
8
Spacer
431577
$1,32 Unit Price incl. VAT
9
Spacer
876413
$7,05 Unit Price incl. VAT
10
Pad
431578
$0,60 Unit Price incl. VAT
11
Washer 6.4x13x1.5
013777
$0,08 Unit Price incl. VAT
12
Screw
620068
$3,65 Unit Price incl. VAT
13
Retainer buffer
871458
$1,09 Unit Price incl. VAT
14
Transmission cover
CM155109
$6,30 Unit Price incl. VAT
15
Soundproof cover with U.P.
1A000476
$36,46 Unit Price incl. VAT
15
Transmission soundproofing cover
877845
Not Available
16
Filtering element
875701
$1,43 Unit Price incl. VAT
17
Hose clamp
844964
$0,25 Unit Price incl. VAT

Find the detailed Crankcase cover - Crankcase cooling GILERA PIAGGIO VESPA diagram on this page. This exploded view allows you to identify the various components you need to maintain your machine and quickly find their original GILERA PIAGGIO VESPA part number.


The diagrams are not contractually binding. If you have any doubts, our professionals are available to answer your questions. When adding a part to your cart, make sure to order the desired quantity. The unit price shown is the price for each reference at a quantity of 1.
