1
Engine displacement
300
2
Model
BEVERLY
3
Year
2015
4
Trim
BEVERLY RST/S 4T 4V IE E3
5
Parts Catalog
Fuel tank
6
Parts Diagram
Parts Catalog
Saddle/seats
by
Air filter
Fuel tank
1
2
3
4
5
6
7
8
9
10
11
12
13
13
14
15
16
17
18
19
19
20
1
Fuel tank
672953
Not Available
1
Fuel tank
674875
$112,40 Unit Price incl. VAT
1
Fuel tank
656842
Not Available
2
Indicator fuel level
CM025719
$96,83 Unit Price incl. VAT
2
Indicator fuel level
CM025706
$110,21 Unit Price incl. VAT
2
Indicator fuel level
CM025718
$83,46 Unit Price incl. VAT
3
Lock kit
657220
Not Available
4
Hex socket screw M4x30
655539
$3,65 Unit Price incl. VAT
5
Hex socket screw M4x16
959559
$0,25 Unit Price incl. VAT
6
Ring nut fuel filler cap
657233
$16,59 Unit Price incl. VAT
6
Ring nut fuel filler cap
1B000258
$10,67 Unit Price incl. VAT
7
Fuel tank filler cap
959465
$17,36 Unit Price incl. VAT
8
Scheibe
959263
$0,67 Unit Price incl. VAT
9
Hose clamp
CM001920
$3,65 Unit Price incl. VAT
10
Hose
959230
Not Available
10
Hose
673778
$35,10 Unit Price incl. VAT
11
Hose clamp
CM001919
$0,77 Unit Price incl. VAT
12
Flat washer 6,5x21
268304
$0,42 Unit Price incl. VAT
13
Washer
078307
$0,17 Unit Price incl. VAT
14
Screw m6x12
031086
$0,08 Unit Price incl. VAT
15
Pad
1B000888
$0,25 Unit Price incl. VAT
16
screw M6x16
031088
$0,17 Unit Price incl. VAT
17
Complete breather pipe
674876
Not Available
18
Elastic spring
231590
$0,25 Unit Price incl. VAT
18
Spring
641652
$0,34 Unit Price incl. VAT
19
Hose clamp
CM001914
$0,75 Unit Price incl. VAT
20
Safety valve
576748
$28,44 Unit Price incl. VAT

Find the detailed Fuel tank GILERA PIAGGIO VESPA diagram on this page. This exploded view allows you to identify the various components you need to maintain your machine and quickly find their original GILERA PIAGGIO VESPA part number.


The diagrams are not contractually binding. If you have any doubts, our professionals are available to answer your questions. When adding a part to your cart, make sure to order the desired quantity. The unit price shown is the price for each reference at a quantity of 1.
