1
Engine displacement
125
2
Model
PX
3
Year
0
4
Trim
PX 125 E
5
Parts Catalog
Gear group
6
Parts Diagram
Parts Catalog
Rear shock absorber
by
Clutch-throttle transmissions
Gear group
1
2
3
4
5
6
7
8
9
10
10
11
11
12
13
1
Oil seal
118058
$10,95 Unit Price incl. VAT
2
Snap ring
018447
Not Available
3
Bearing 20x47x14
434735
$7,12 Unit Price incl. VAT
4
Drive shaft
2359085
Not Available
5
Gear
2232295
Not Available
6
Gear
2232335
Not Available
7
Gear
1528055
Not Available
8
Gear
2232265
Not Available
9
Selector spindle
2232325
Not Available
10
Snap ring
009101
$3,65 Unit Price incl. VAT
11
Ring 2° magg.
165417
$3,65 Unit Price incl. VAT
11
Ring
165415
$3,08 Unit Price incl. VAT
11
Ring 1° magg.
165418
$1,76 Unit Price incl. VAT
11
Ring
138393
$1,37 Unit Price incl. VAT
11
Ring
165416
$4,01 Unit Price incl. VAT
12
Gear selector
2232255
Not Available
13
Dust cover
243154
$16,33 Unit Price incl. VAT
The diagrams are provided for reference only. If in doubt, our specialists are available to answer your questions. When adding a part to your cart, please make sure to select the desired quantity. The unit price shown is the price for one unit of each part number.
