Parts Catalog
Electrical systems
6
Parts Diagram
Parts Catalog
Electrical systems
by
Brake lever
Electrical systems
1
2
3
3
4
5
6
7
8
9
10
11
12
13
14
15
16
1
Spring pin
101481
$0,16 Unit Price incl. VAT
2
Grip, l.h.
274489
$13,41 Unit Price incl. VAT
2
GRIP
266187
Not Available
3
BEARING
266535
Not Available
4
THROTTLE CON.
265991
Not Available
5
Washer
177148
$0,38 Unit Price incl. VAT
6
Washer
177147
$2,95 Unit Price incl. VAT
7
PULLEY
267962
Not Available
8
screw
265943
Not Available
9
LEVER
274547
Not Available
9
LEVER
265947
Not Available
10
Flat washer 6,4x12x1
003056
$0,08 Unit Price incl. VAT
11
SPRING
265606
Not Available
12
Spacer
265944
Not Available
13
LEVER
265946
Not Available
14
Flat washer 15x8,4x1,5
003058
$0,08 Unit Price incl. VAT
15
Washer
006968
$2,95 Unit Price incl. VAT
16
SLEEVE
274549
Not Available
16
THROTTLE GRIP
265945
Not Available

Find the detailed :label GILERA PIAGGIO VESPA diagram on this page. This exploded view allows you to identify the various components you need to maintain your machine and quickly find their original GILERA PIAGGIO VESPA part number.


The diagrams are not contractually binding. If you have any doubts, our professionals are available to answer your questions. When adding a part to your cart, make sure to order the desired quantity. The unit price shown is the price for each reference at a quantity of 1.
