1
Engine displacement
500
2
Model
X9
3
Year
2006
4
Trim
X9 Evolution
5
Parts Catalog
Fork/steering tube - Steering bearing unit
6
Parts Diagram
Parts Catalog
Swinging arm
by
Rear suspension - Shock absorber/s
Fork/steering tube - Steering bearing unit
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
22
23
24
25
26
27
1
Steering bear. assy.
598261
Not Available
2
Front fork
601118
Not Available
3
Steering tube ring nut
011109
Not Available
3
Steering tube ring nut
0111094
$2,60 Unit Price incl. VAT
4
Steering security plate
582787
$3,65 Unit Price incl. VAT
5
plate
599499
Not Available
6
Sleeve
599549
Not Available
6
Sleeve
599550
Not Available
7
screw M8x40 (Marzocchi)
599511
Not Available
8
screw M6x25 (Marzocchi)
599512
$3,65 Unit Price incl. VAT
9
screw M10x30 (Marzocchi)
599513
Not Available
10
Cup (Marzocchi)
599504
$1,92 Unit Price incl. VAT
11
Disc cover bush
599510
$3,40 Unit Price incl. VAT
12
Washer (Marzocchi)
599572
Not Available
13
Gasket ring (Marzocchi)
599501
$9,40 Unit Price incl. VAT
14
Pad (Marzocchi)
599509
$11,77 Unit Price incl. VAT
15
Stop ring (Marzocchi)
599503
Not Available
16
Dust cover + spring (Marzocchi)
599502
$8,58 Unit Price incl. VAT
17
Upper bush (Marzocchi)
599505
Not Available
18
Lower bush
599629
Not Available
19
Sleeve
599500
Not Available
20
Cover
601026
$0,84 Unit Price incl. VAT
22
Stop ring (Marzocchi)
601284
$4,82 Unit Price incl. VAT
23
Stop ring (Marzocchi)
601287
Not Available
24
FORK O-RING X9 500
601350
Not Available
25
Fork spacer
601351
$3,65 Unit Price incl. VAT
26
FORK STEM
601352
Not Available
27
Cover
621365
$4,82 Unit Price incl. VAT
The diagrams are provided for reference only. If in doubt, our specialists are available to answer your questions. When adding a part to your cart, please make sure to select the desired quantity. The unit price shown is the price for one unit of each part number.
