Displacement

Model

Year

Finish line

Parts catalogue

Parts diagram

Cylinder-piston-wrist pin unit

DRIVEN PULLEY FOR PIAGGIO BV ST 4T 4V IE E4 ABS 2017

Driving pulley

Item numbers
Driven pulley PIAGGIO PIAGGIO-SCOOTER 350 BV 2017 BV ST 4T 4V ie E4 ABS
1
2
3
4
5
6
7
8
9
10
11
12
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
1
CLUTCH COVER

B019116  

Unit Price

2
GASKET

B015679  

Unit Price

3
GASKET RING 40X25X7

873931  

Unit Price

4
RADIAL BALL BEARING

878881  

Unit Price

5
HEX SCREW M6X20

018639  

Unit Price

6
CLUTCH DRIVEN PULLEY ASSY.

B015114  

Unit Price

7
GASKET

B013688  

Unit Price

8
ADJUSTABLE PULLEY, HALF

879389  

Unit Price

9
GASKET

878162  

Unit Price

10
PULLEY SIDE CAP

B014906  

Unit Price

11
SLIDING WASHER

B014599  

Unit Price

12
SPRING SEAT

B015110  

Unit Price

13
VARIATOR SPRING

B015119  

Unit Price

14
SPRING SEAT

B015109  

Unit Price

15
RING NUT

433232  

Unit Price

16
FLAT WASHER

878953  

Unit Price

17
SCREW W/ FLANGE

878950  

Unit Price

18
CENTRIFUGAL CLUTCH ASSEMBLY

B019015  

Contact
19
RING NUT

B014882  

Unit Price

20
DRIVE SHAFT

878741  

Unit Price

21
CLUTCH HUB

B013469  

1A003807

Unit Price

22
SNAP RING

876986  

Unit Price

23
DISCS RETAINING RING

876987  

Unit Price

24
BELLEVILLE SPRING

B014176  

Unit Price

25
UPPER SPRING HOLDER DISC

B019014  

Unit Price

26
COVERED DUCT PLATE

876976  

Contact
27
DRIVEN CLUTCH DISC

876975  

Contact
28
DRIVING CLUTCH DISC

B019012  

Contact
29
SNAP RING

B014186  

Unit Price

30
LOWER SPRING HOLDER DISC

B019013  

Contact
31
ROLLER COMPLETE

876977  

Unit Price

32
FLAT WASHER

878743  

Unit Price

33
DRIVEN PULLEY SHAFT

878718  

Unit Price

34
ROLLER CAGE

878782  

Unit Price

35
CLUTCH SPRING

B019008  

Unit Price

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from PIAGGIO. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.

Find on this page all the original spare parts relating to the Driven pulley of your PIAGGIO BV ST 4T 4V ie E4 ABS of BV. Let us know if you have any questions.

Genuine parts for PIAGGIO BV ST 4T 4V ie E4 ABS 2017

Engine Frame - Plastic parts - Coachwork Handlebars/Steering Suspensions - Wheels Braking system - Transmissions Electrical system

PIAGGIO BV ST 4T 4V ie E4 ABS 2017

Choose the exact model of your PIAGGIO BV 350 to access the different categories of genuine spare parts

350 BV 2017 BV ST 4T 4V ie E4 ABS

BV ST 4T 4V ie E4 ABS

PIAGGIO-SCOOTER BV

Displacement: 350 cc
Year: 2017
