Front headlamps - Turn signal lamps

MAIN CABLE HARNESS FOR PIAGGIO BV ST 4T 4V IE E4 ABS 2017

Rear headlamps - Turn signal lamps

Item numbers

CABLE HARNESS

1D001809

$1 421,71

Unit Price

CONNECTORS SUPPORT BRACKET

641938

$19,68

Unit Price

SCREW W/ FLANGE M6X16

B016777

$3,65

Unit Price

MINI FUSE 5A

CM080904

$5,38

Unit Price

MINI FUSE 10A

CM080906

$4,82

Unit Price

MINI FUSE 15A

CM080907

$5,38

Unit Price

MINI FUSE 20A

CM080908

$4,32

Unit Price

PLUG CONNECT DIAGNOS ECU

582928

$4,36

Unit Price

MASS CABLE

643026

$17,69

Unit Price

TRI/LOBED HEXAGONAL SELF-TAPPING SCREW

641204

$0,19

Unit Price

SPRING WASHER 6, 4X11, 8X1

016406

$3,65

Unit Price

FLAT WASHER 6, 4X12X1

003056

$3,65

Unit Price

AMBIENT TEMPERATURE SENSOR

581142

Contact

USB PORT

1D001377

Contact

FAIRLEAD

1B001591

$4,29

Unit Price

WATER PUMP CONNECTION PLUG

641754

Contact

LOCK-STRAP L=180MM

145298

$3,38

Unit Price

SHEET EDGE SPRING

CM013203

$5,23

Unit Price

LOCK-STRAP L=180MM

145298

$3,38

Unit Price

ELASTIC SPRING

231590

$2,66

Unit Price

LOCK-STRAP

641605

$3,65

Unit Price

PIPES/CABLES RETAINER SPRING L=16

CM006907

$5,38

Unit Price

NON RETURN SPRING

CM006902

$5,38

Unit Price

SPRING FOR CONNECTOR

639560

$8,65

Unit Price

LOCK-STRAP L=180MM

145298

$3,38

Unit Price

LOCK-STRAP L=277

257134

$0,09

Unit Price

PIPES/CABLES RETAINER SPRING

CM006903

$5,38

Unit Price

MAINTENANCE

584002

$4,82

Unit Price

NON RETURN SPRING L=12

CM006905

$5,38

Unit Price

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from PIAGGIO. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.

Find on this page all the original spare parts relating to the Main cable harness of your PIAGGIO BV ST 4T 4V ie E4 ABS of BV. Let us know if you have any questions.
