1
Engine displacement
150
2
Model
MEDLEY
3
Year
2017
4
Trim
Medley 4T ie ABS
5
Parts Catalog
Tank
6
Parts Diagram
Parts Catalog
Cooling system
by
Handlebars - Master cil.
Tank
2
3
4
5
6
6
7
7
8
8
9
10
11
12
13
14
15
17
20
20
20
20
21
21
21
22
23
24
25
26
26
28
29
18A
19A
27B
1A
27A
1B
16A
19B
27C
16B
18B
1A
Réservoir de carburant complet.
1B002003
$55,57 Unit Price incl. VAT
1B
Réservoir de carburant complet.
1B002950
$71,29 Unit Price incl. VAT
2
Indicateur niveau essence
1D001226
$17,24 Unit Price incl. VAT
3
Gasket
676200
$13,47 Unit Price incl. VAT
4
Nut
709116
$0,59 Unit Price incl. VAT
5
Flat washer 16x6,5x1,5
013880
$0,08 Unit Price incl. VAT
6
Kit serrures
1B004018
$97,90 Unit Price incl. VAT
6
Kit serrures
1B002511
Not Available
7
Hex socket screw M4x16
959559
$0,25 Unit Price incl. VAT
7
Hex socket screw M4x30
655539
$3,65 Unit Price incl. VAT
8
Fuel tank filler cap
959465
$17,36 Unit Price incl. VAT
8
Tubulure rempl.rés.ess.
1B003970
$4,33 Unit Price incl. VAT
9
Hose
673778
$35,10 Unit Price incl. VAT
10
Hose clamp
CM001920
$3,65 Unit Price incl. VAT
11
Hose clamp
CM001919
$0,77 Unit Price incl. VAT
12
Hex screw M6x20
018639
$0,16 Unit Price incl. VAT
13
Spring washer 6,4x11,8x1
016406
$0,34 Unit Price incl. VAT
14
Flat washer 16x6,5x1,5
013880
$0,08 Unit Price incl. VAT
15
Spring plate M6
254485
$0,34 Unit Price incl. VAT
16A
Fuel pump
642888
$206,95 Unit Price incl. VAT
16B
Fuel pump cpl.
1D001375
$109,50 Unit Price incl. VAT
17
O-ring
781056
$3,65 Unit Price incl. VAT
18A
Gasket
1B002841
$2,70 Unit Price incl. VAT
18B
Gasket
1B002953
$2,89 Unit Price incl. VAT
19A
Bride pompe essence
5A000067
Not Available
19B
Bride pompe essence
1B002952
$2,52 Unit Price incl. VAT
20
Nut
709116
$0,59 Unit Price incl. VAT
21
Tuyau de carburant compl.
1B004080R
$48,89 Unit Price incl. VAT
21
Tuyau de carburant compl.
1B003548R
$50,48 Unit Price incl. VAT
21
Tuyau de carburant compl.
1B005553R
$46,10 Unit Price incl. VAT
22
Wiring clip
1B001321
$1,43 Unit Price incl. VAT
23
Screw w/ flange M6x10
969296
$0,16 Unit Price incl. VAT
24
Non return spring
CM006911
$0,42 Unit Price incl. VAT
25
Reniflard complet
1B0027645
$26,72 Unit Price incl. VAT
26
Safety valve
1B005112R
$25,22 Unit Price incl. VAT
26
Safety valve
CM179008
$37,24 Unit Price incl. VAT
27A
Patte de blocage tuyau carburant
1B004004
$1,75 Unit Price incl. VAT
27B
Fuel pump bracket
1B004048
$0,93 Unit Price incl. VAT
27C
Patte de blocage tuyau carburant
1B004100
$0,93 Unit Price incl. VAT
28
Stop nut M5-6H DIN 985
804457
$0,16 Unit Price incl. VAT
29
Hose clamp
CM001901
$0,76 Unit Price incl. VAT
The diagrams are provided for reference only. If in doubt, our specialists are available to answer your questions. When adding a part to your cart, please make sure to select the desired quantity. The unit price shown is the price for one unit of each part number.
