Transmissions
1
1
1
1
2
2
3
3
4
4
5
5
6
6
7
7
8
8
9
9
10
10
11
11
12
12
13
13
14
14
15
15
16
16
1
Rear brake lever complete transmission
1C002490
Not Available
1
Transmission complète de commande de frein arrière
1C005814
Not Available
2
Adjuster pin
179640
$1,09 Unit Price incl. VAT
3
Registro freno posteriore
270310
$1,68 Unit Price incl. VAT
4
Plate
1C001736
$1,43 Unit Price incl. VAT
5
Hex socket screw M6x20
709674
$0,17 Unit Price incl. VAT
6
Wiring clip
1C000589
$7,84 Unit Price incl. VAT
7
Lock-strap L=277
257134
$0,25 Unit Price incl. VAT
8
Lock-strap L=180mm
145298
$0,08 Unit Price incl. VAT
9
Hose clamp
298729
$0,34 Unit Price incl. VAT
10
Pipes/cables retainer spring
CM013202
$1,10 Unit Price incl. VAT
11
Hose clamp
648891
$2,95 Unit Price incl. VAT
12
Self tapping screw 4,2x16
015911
$2,25 Unit Price incl. VAT
13
Plate
CM017408
$0,25 Unit Price incl. VAT
14
Hose clamp
298729
$0,34 Unit Price incl. VAT
15
Pipes/cables retainer spring
CM006903
$1,43 Unit Price incl. VAT
16
Washer
013836
$0,09 Unit Price incl. VAT
The diagrams are provided for reference only. If in doubt, our specialists are available to answer your questions. When adding a part to your cart, please make sure to select the desired quantity. The unit price shown is the price for one unit of each part number.
