1
Engine displacement
300
2
Model
GTV
3
Year
2010
4
Trim
GTV 4T 4V ie Touring
5
Parts Catalog
ABS Brake system
6
Parts Diagram
Parts Catalog
Cooler pump
by
Wheel huosing - Mudguard
ABS Brake system
29
28
27
26
25
24
23
22
21
20
19
18
17
16
16
16
16
15
15
15
15
15
14
13
12
11
10
9
8
7
6
6
5
5
5
5
4
4
3
2
1
1
ABS electro-hydraulic control unit
1C001631
$1 736,10 Unit Price incl. VAT
2
Support clamp ABS
1C000266
$17,07 Unit Price incl. VAT
3
Hex screw M6x20
018639
$0,16 Unit Price incl. VAT
4
Hex screw M6x20
018639
$0,16 Unit Price incl. VAT
5
Spacer
1C000253
$0,34 Unit Price incl. VAT
6
Pad
939278
$0,34 Unit Price incl. VAT
7
Fixture rod
1C000171
$17,07 Unit Price incl. VAT
8
Nut
969224
$0,42 Unit Price incl. VAT
9
Complete bracket
1C000890
$15,98 Unit Price incl. VAT
10
Front brake caliper
CM068320
$132,30 Unit Price incl. VAT
11
Brake pads couple
668021
$105,58 Unit Price incl. VAT
12
Brake supp. plate pin
666139
$7,56 Unit Price incl. VAT
13
Hex socket screw M8x40
149104
$0,51 Unit Price incl. VAT
14
Spring washer
709047
$0,08 Unit Price incl. VAT
15
Gasket
127927
$0,25 Unit Price incl. VAT
16
Oil pipe screw M10x18
265451
$9,25 Unit Price incl. VAT
17
Pinza freno Heng Tong
CM074101
$86,40 Unit Price incl. VAT
18
Rear Brake pads couple.
647161
$36,45 Unit Price incl. VAT
19
screw
319532
$3,65 Unit Price incl. VAT
20
Spring washer
709047
$0,08 Unit Price incl. VAT
21
Flat washer 15x8,4x1,5
003058
$0,08 Unit Price incl. VAT
22
ABS unit right brake pump pipe
1C001255
$75,98 Unit Price incl. VAT
23
ABS unit right brake pump pipe
1C001254
$75,98 Unit Price incl. VAT
24
ABS unit brake pipe - front brake pin
1C000272
$67,34 Unit Price incl. VAT
25
Rear brake - junction - ABS unit pip
1C000630
$72,01 Unit Price incl. VAT
26
Rear brake pipe
1C000677
$131,41 Unit Price incl. VAT
27
Screw w/ flange M6x16
B016777
$0,16 Unit Price incl. VAT
28
Screw w/ flange M6x16
B016777
$0,16 Unit Price incl. VAT
29
Flat washer 8,2x17x2,5
828961
$0,28 Unit Price incl. VAT
The diagrams are provided for reference only. If in doubt, our specialists are available to answer your questions. When adding a part to your cart, please make sure to select the desired quantity. The unit price shown is the price for one unit of each part number.
