REAR SUSPENSION - SHOCK ABSORBER / S FOR PIAGGIO X10 4T 4V I.E. E3 2012

Rear wheel

Item numbers

BRACCIO SOSPENSIONE DX COMPLETO

1A000008

$166,72

Unit Price

BRACCIO SOSPENSIONE DX COMPLETO

B015352

$152,54

Unit Price

BALL BEARING

82545R

$41,85

Unit Price

CIRCLIP

006647

$3,38

Unit Price

COMPLETE REAR SUSPENSION LINKAGE

669245

$269,00

Unit Price

ROLLER CAGE 25X32X16

668257

$15,13

Unit Price

RADIAL BEARING

82627R

$18,14

Unit Price

SNAP RING

006637

$0,33

Unit Price

SHAFT

667805

$135,07

Unit Price

STEERING TUBE RING NUT

0111094

$7,23

Unit Price

SPACER

668258

$4,73

Unit Price

SPACER

667644

$32,68

Unit Price

THREADED BUSH

668677

$27,67

Unit Price

REAR WHEEL SPINDLE NUT

648708

Contact

COMPLETE REAR SHOCK ABSORBER

667793

$1 120,95

Unit Price

SHOCK ABSORBER CONNECTION BRACKET

668288

$32,69

Unit Price

HEX SCREW

669075

Contact

NUT M12

271740

$3,30

Unit Price

NUT M14X1, 5

006844

$2,97

Unit Price

RIGHT STRUT SET

669250

$82,74

Unit Price

LEFT STRUT SET

669220

$63,59

Unit Price

HEX SCREW

668329

$0,82

Unit Price

SELF LOCKING NUT M10

002440

$3,65

Unit Price

RIGHT STRUT SUPPORT BRACKET

668279

$11,39

Unit Price

HEX SOCKET SCREW

826298

$3,38

Unit Price

SPRING WASHER

709047

$0,05

Unit Price

LEFT STRUT FIXING BRACKET

667803

$9,04

Unit Price

HEX SOCKET SCREW M8X50

844483

$0,29

Unit Price

SPRING WASHER

709047

$0,05

Unit Price

NUT M8
NUT

195483

020008

$3,65

Unit Price

HEX SOCKET SCREW M12X1, 25

668817

$3,96

Unit Price

HOSE CLAMP

668282

$2,76

Unit Price

SCREW
SCREW M8X25

271596

597150

$3,65

Unit Price

SPRING WASHER

709047

$0,05

Unit Price

LOCK-STRAP L=277

257134

$0,09

Unit Price

WASHER

006982

$1,54

Unit Price

SPACER

669222

$9,41

Unit Price

NUT M10X1, 25 6H

833520

$2,66

Unit Price

SCREW

018622

$3,78

Unit Price

SIL.BLOCK

880343

$11,77

Unit Price

ROLLER CAGE

56127R

$3,65

Unit Price

SIL.BLOCK

880343

$11,77

Unit Price

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from PIAGGIO. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
When adding a part to your cart, be careful to order the required quantity. Please note that the unit price indicated is the price for each part number in quantity 1.
Our parts are original and brand new spare parts of PIAGGIO, to guarantee you quality and durable components. If you have any questions, we are here to help. Order your spare parts today and receive them directly at home!
