Displacement

Model

Year

Finish line

Parts catalogue

Parts diagram

Handlebars coverages

HANDLEBARS - MASTER CIL. FOR PIAGGIO X10 4T 4V I.E. E3 2012

Meter combination - Cruscotto

Item numbers
Handlebars - Master cil. PIAGGIO PIAGGIO-SCOOTER 500 X10 2012 X10 4T 4V I.E. E3
1
2
2
3
4
5
6
7
8
9
10
11
12
12
13
14
15
16
17
18
19
19
20
20
21
22
23
24
25
1
HANDLEBAR WITH U.P.

6741055  

Unit Price

2
LEFT BRAKE HYDRAULIC PUMP

CM086403  

Contact
2
LEFT BRAKE HYDRAULIC PUMP

CM086405  

Contact
3
BRAKE LEVER

668417  

Unit Price

4
BRACKET

668387  

Unit Price

5
LH HOSE

667957  

Contact
6
GRIP, L.H.

CM084201  

Unit Price

7
COMPLETE RIGHT THROTTLE CONTROL GRIP

CM088201  

Contact
8
GRIP, R.H.

CM084202  

Unit Price

9
THROTTLE OPENING TRANSMISSION

668246  

Unit Price

10
THROTTLE CLOSING TRANSMISSION

668247  

Unit Price

11
ELECTRIC CONTROL DEVICE DX

643152  

Contact
12
RIGHT HYDRAULIC BRAKE PUMP
RIGHT HYDRAULIC BRAKE PUMP

CM086404  

CM086408

Unit Price

13
BRAKE LEVER

668417  

Unit Price

14
BRACKET

668535  

Unit Price

15
HEX SOCKET SCREW M10X65

674421  

Unit Price

16
NUT M10

015330  

Unit Price

17
FLAT WASHER

178790  

Unit Price

18
FLAT ELASTIC WASHER WITH INTERNAL TOOTHING 17X10, 3X2

012543  

Unit Price

19
HANDLEBAR TERMINAL

675829  

Unit Price

20
COUNTERSUNK HEAD TORX SREW
COUNTERSUNK HEAD TORX SCREW

271434  

1B006376

Unit Price

21
FASCETTA CON P.I.

666620  

Unit Price

22
SCREW W/ FLANGE M6X16
FLANGED HEXAGONAL SCREW M6X16

434541  

B016777

Unit Price

23
LOCK-STRAP L=277

257134  

Unit Price

24
HOSE CLAMP 2, 7X132

640879  

Unit Price

25
STRAP

216369  

Contact
Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from PIAGGIO. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
When adding a part to your cart, be careful to order the required quantity. Please note that the unit price indicated is the price for each part number in quantity 1.
Our parts are original and brand new spare parts of PIAGGIO, to guarantee you quality and durable components. If you have any questions, we are here to help. Order your spare parts today and receive them directly at home!

Genuine parts for PIAGGIO X10 4T 4V I.E. E3 2012

Engine Frame - Plastic parts - Coachwork Handlebars/Steering Suspensions - Wheels Braking system - Transmissions Electrical system

PIAGGIO X10 4T 4V I.E. E3 2012

All the genuine spare parts for the PIAGGIO 2012

500 X10 2012 X10 4T 4V I.E. E3

X10 4T 4V I.E. E3

PIAGGIO-SCOOTER X10

Displacement: 500 cc
Year: 2012
