HELMET HUOSING - UNDERSADDLE FOR PIAGGIO MP3 500 2009

Locks

Item numbers
Helmet huosing - Undersaddle PIAGGIO PIAGGIO-SCOOTER 500 MP3 2009 MP3 500
1
2
3
4
5
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
1
HELMET HOLDER ASSEMBLY

653442  

Unit Price

2
SCREW M6X16

272836  

Unit Price

3
WASHER

297029  

Unit Price

4
SCREW M6X16

272836  

Unit Price

5
SPRING PLATE M6

254485  

Unit Price

6
SPRING PLATE

CM017410  

Unit Price

7
SELF TAPPING SCREW M4X16

267115  

Unit Price

8
EXPANSION PLUG

199190  

Unit Price

9
HELMET HOLDER ASSEMBLY
COMPLETE HELMET HOLDER

653443  

653442

Unit Price

10
INJECTION UNIT ACCESS COVER

623599  

Unit Price

11
SELF TAPPING SCREW 4, 2X16
THREAD FORMING SCREW

270723  

CM178606

Unit Price

12
COMPLETE BATTERY COVER

653707  

Unit Price

13
PAD
BUFFER

575329  

583310

Unit Price

14
SELF TAPPING SCREW 4, 2X16
THREAD FORMING SCREW

270723  

CM178606

Unit Price

15
SCREW M6X16

624995  

Unit Price

16
NUT

020006  

Unit Price

17
TYPE-TESTING INSPECTION DOOR

576793  

Unit Price

18
LV SOCKET 12V

294770  

Unit Price

19
CEILING BOWL

293154  

Unit Price

20
TORPEDO SHAPED LAMP 12V-5W

071633  

Unit Price

21
PROTECTIVE BUFFER

653428  

Unit Price

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from PIAGGIO. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.

Find on this page all the original spare parts relating to the Helmet huosing - Undersaddle of your PIAGGIO MP3 500 of MP3. Let us know if you have any questions.
