COOLING SYSTEM FOR PIAGGIO MP3 500 2009

Wheel huosing - Mudguard

Item numbers

WATER COOLER
RADIATOR WATER

653468

1B001908

$262,83

Unit Price

SCREW M6X16

272836

$0,09

Unit Price

SPRING PLATE M6

254485

$3,30

Unit Price

LOWER RUBBER

258904

$5,53

Unit Price

TEMPERATURE GAUGE

584715

$24,35

Unit Price

ELECTRIC FAN ASSY.
ELECTRIC FAN

640389

58211R

$148,33

Unit Price

SCREW M6X16

272836

$0,09

Unit Price

SPRING PLATE M6

254485

$3,30

Unit Price

COOLANT TANK

653463

Contact

EXPANSION TANK PLUG

623673

$4,85

Unit Price

SCREW 4, 2X19

258249

$0,09

Unit Price

SPRING PLATE

CM017410

$3,65

Unit Price

LOWER RUBBER

258904

$5,53

Unit Price

COOLER-EXPANSION TANK PIPE

622582

$7,23

Unit Price

MANIFOLD-UNION BREATHER PIPE

622581

$8,16

Unit Price

HOSE CLAMP

CM001903

$3,65

Unit Price

HOSE CLAMP

CM001904

$3,65

Unit Price

PUMP-RADIATOR PIPE FITTING

652618

$72,85

Unit Price

RADIATOR-HEAD PIPE FITTING LINK

652619

$67,48

Unit Price

HOSE CLAMP

CM001907

$3,65

Unit Price

HOSE CLAMP

CM001908

$3,65

Unit Price

HOSE CLAMP

CM001915

$3,65

Unit Price

NON RETURN SPRING

CM006902

$5,38

Unit Price

PIPES/CABLES RETAINER SPRING

CM006903

$5,38

Unit Price

COMPLETE RADIATOR FRAME

653709

$118,35

Unit Price

SPACER

479882

$0,75

Unit Price

SPRING PLATE

230359

$2,95

Unit Price

SCREW M4, 2X13
SCREW

576189

259349

$2,74

Unit Price

SPRING PLATE

CM017410

$3,65

Unit Price

LOCK-STRAP L=277

257134

$0,09

Unit Price

NON RETURN SPRING

CM017808

$4,82

Unit Price

LOCK-STRAP L=180MM

145298

$3,38

Unit Price

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from PIAGGIO. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.

Find on this page all the original spare parts relating to the Cooling system of your PIAGGIO MP3 500 of MP3. Let us know if you have any questions.
