HANDLEBARS - MASTER CIL. FOR PIAGGIO CARNABY 4T IE E3 2008

Meter combination - Cruscotto

Item numbers
Handlebars - Master cil. PIAGGIO PIAGGIO-SCOOTER 250 CARNABY 2008 Carnaby 4T ie E3
1
2
3
4
5
5
9
9
10
11
12
13
14
14
15
16
17
17
18
18
19
20
20
21
21
22
23
24
25
1
HANDLEBARS WITH I.P.

652944  

Contact
2
FLAT ELASTIC WASHER WITH INTERNAL TOOTHING 17X10, 3X2

012543  

Unit Price

3
FLAT WASHER

178790  

Unit Price

4
NUT M10

015330  

Unit Price

5
HEX SOCKET SCREW

655554  

Unit Price

9
HANDLEBAR TERMINAL
HANDLEBAR TAG

653017  

654603

Unit Price

10
COMPLETE GAS CONTROL MUFF

CM079722  

Contact
11
GRIP, L.H.

271452  

Unit Price

12
GRIP, R.H.

271453  

Unit Price

13
GAS OPENING TRANSMISSION

650275  

Unit Price

14
SCREW

576836  

Unit Price

15
GAS CLOSING TRANSMISSION

650276  

Contact
16
BRAKE M.CYL. DX

56359R  

Unit Price

17
BRAKE LEVER HENG TONG

600475  

Unit Price

17
BRAKE LEVER (BREMBO)

646829  

Unit Price

18
U-BOLT (BREMBO)

497343  

Unit Price

18
U-BOLT HENG TONG

600478  

Unit Price

19
LEFT BRAKE HYDRAULIC PUMP

56360R  

Unit Price

20
U-BOLT (BREMBO)

497343  

Unit Price

20
U-BOLT HENG TONG

600478  

Unit Price

21
BRAKE LEVER HENG TONG

600475  

Unit Price

21
BRAKE LEVER (BREMBO)

646829  

Unit Price

22
NON RETURN SPRING L=12

CM006905  

Unit Price

23
LOCK-STRAP L=180MM

145298  

Unit Price

24
SCREW W/ FLANGE M6X16
FLANGED HEXAGONAL SCREW M6X16

434541  

B016777

Unit Price

25
SELF LOCKING NUT M6

288245  

Unit Price

26
LOCK-STRAP L=277

257134  

Unit Price

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from PIAGGIO. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.

Find on this page all the original spare parts relating to the Handlebars - Master cil. of your PIAGGIO Carnaby 4T ie E3 of CARNABY. Let us know if you have any questions.

Genuine parts for PIAGGIO Carnaby 4T ie E3 2008

Engine Frame - Plastic parts - Coachwork Handlebars/Steering Suspensions - Wheels Braking system - Transmissions Electrical system

PIAGGIO Carnaby 4T ie E3 2008

Choose the exact model of your PIAGGIO CARNABY 250 to access the different categories of genuine spare parts

250 CARNABY 2008 Carnaby 4T ie E3

Carnaby 4T ie E3

PIAGGIO-SCOOTER CARNABY

Displacement: 250 cc
Year: 2008
