Displacement

Model

Year

Finish line

Parts catalogue

Parts diagram

Fuel tank

HELMET HUOSING - UNDERSADDLE FOR PIAGGIO CARNABY 4T IE E3 2008

Locks

Item numbers
Helmet huosing - Undersaddle PIAGGIO PIAGGIO-SCOOTER 250 CARNABY 2008 Carnaby 4T ie E3
1
2
3
4
5
6
7
8
9
10
11
12
1
HELMET COMPARTMENT

654164  

Contact
2
SCREW M6X16

272836  

Unit Price

3
SPRING PLATE M6

254485  

Unit Price

4
RH INTERNAL OBJECT HOLDER COMPARTMENT

653378  

Contact
5
RH EXTERNAL OBJECT HOLDER COMPARTMENT

653379  

Contact
6
LH INTERNAL OBJECT HOLDER COMPARTMENT

653376  

Unit Price

7
LH EXTERNAL OBJECT HOLDER COMPARTMENT

653377  

Unit Price

8
SELF TAPPING SCREW
SELF TAPPING SCREW

296141  

297498

Unit Price

9
COVER

AP8127826  

Unit Price

10
SELF TAPPING SCREW
SELF TAPPING SCREW

296141  

297498

Unit Price

11
REAR PLATE PLUG

654169  

Unit Price

12
RUBBER SPACER

AP8706409  

Unit Price

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from PIAGGIO. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.

Find on this page all the original spare parts relating to the Helmet huosing - Undersaddle of your PIAGGIO Carnaby 4T ie E3 of CARNABY. Let us know if you have any questions.

Genuine parts for PIAGGIO Carnaby 4T ie E3 2008

Engine Frame - Plastic parts - Coachwork Handlebars/Steering Suspensions - Wheels Braking system - Transmissions Electrical system

PIAGGIO Carnaby 4T ie E3 2008

Choose the exact model of your PIAGGIO CARNABY 250 to access the different categories of genuine spare parts

250 CARNABY 2008 Carnaby 4T ie E3

Carnaby 4T ie E3

PIAGGIO-SCOOTER CARNABY

Displacement: 250 cc
Year: 2008
