1
Engine displacement
50
2
Model
NRG
3
Year
0
4
Trim
NRG MC3
5
Parts Catalog
Side covers
6
Parts Diagram
Parts Catalog
Fuel tank
by
Front and rear mudguard
Side covers
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
26
27
28
29
30
31
32
33
34
35
36
37
38
39
4
Metric screw TBC
575249
$0,66 Unit Price incl. VAT
5
Spring plate M6
254485
$0,34 Unit Price incl. VAT
6
Guard
575144000C
Not Available
7
Number plate support
5801754
Not Available
7
Number plate holder
2929224
Not Available
7
Number plate holder support
2924654
$2,41 Unit Price incl. VAT
8
Rivet
273074
$3,65 Unit Price incl. VAT
9
Spring plate M6
254485
$0,34 Unit Price incl. VAT
10
Metric screw TBC
575249
$0,66 Unit Price incl. VAT
11
Cylinder set
2577032
$7,02 Unit Price incl. VAT
12
Trimmings kit
5769470004
Not Available
12
Trimmings kit
5769470008
Not Available
12
Trimmings kit
5769480009
Not Available
12
Trimmings kit
5769470006
Not Available
13
Air intake
957183000C
Not Available
14
Metric screw TBC
575249
$0,66 Unit Price incl. VAT
15
RH SIDE COVER MC3 686
CM00460250A7
Not Available
15
RH SIDE COVER MC3 682
CM00460250B5
Not Available
15
RH SIDE COVER MC3 280
CM00460250A3
$135,30 Unit Price incl. VAT
15
RH SIDE COVER MC3 679
CM00460250N7
Not Available
15
RH SIDE COVER MC3 94
CM0046025090
$128,94 Unit Price incl. VAT
16
Cam
257532
$5,38 Unit Price incl. VAT
17
Spring
257533
$5,38 Unit Price incl. VAT
18
Plate
008808
$2,95 Unit Price incl. VAT
19
Spring plate M6
254485
$0,34 Unit Price incl. VAT
20
Metric screw TBC
575249
$0,66 Unit Price incl. VAT
21
LH SIDE COVER MC3 682
CM00460150B5
Not Available
21
LH SIDE COVER MC3 686
CM00460150A7
Not Available
21
LH SIDE COVER MC3 94
CM0046015090
Not Available
21
LH SIDE COVER
CM00460150N7
Not Available
21
LH SIDE COVER MC3 280
CM00460150A3
Not Available
22
Air intake
957182000C
$6,08 Unit Price incl. VAT
23
Central cover
957268000C
Not Available
24
screw
008455
$2,25 Unit Price incl. VAT
25
Hook
265093
$10,67 Unit Price incl. VAT
26
Spring plate
184142
Not Available
27
Cover
CM00100250V7
Not Available
27
Cover
CM00100150V7
Not Available
27
Cover
CM00100250G4
Not Available
27
Cover
CM00100150N4
Not Available
27
Cover
CM00100250N4
Not Available
27
Cover
CM00100150N9
Not Available
27
Cover
CM00100250N9
Not Available
27
Cover
CM00100150G4
Not Available
28
Cover
581205000C
Not Available
28
Cover
581204000C
$14,39 Unit Price incl. VAT
29
Spark plug insp. door
957216000C
Not Available
30
Joint
575908
Not Available
31
screw 4,2x19
258249
$0,09 Unit Price incl. VAT
32
Screw M6x16
272836
$3,70 Unit Price incl. VAT
33
screw 4,2x19
258249
$0,09 Unit Price incl. VAT
34
Spring plate
184142
Not Available
35
screw 3,5x16
015859
$6,60 Unit Price incl. VAT
36
Spring plate
185802
$5,38 Unit Price incl. VAT
37
screw 4,2x19
258249
$0,09 Unit Price incl. VAT
38
Lateral reflector
293556
Not Available
39
"kat" name plate
575736
$4,82 Unit Price incl. VAT

Find the detailed :label GILERA PIAGGIO VESPA diagram on this page. This exploded view allows you to identify the various components you need to maintain your machine and quickly find their original GILERA PIAGGIO VESPA part number.


The diagrams are not contractually binding. If you have any doubts, our professionals are available to answer your questions. When adding a part to your cart, make sure to order the desired quantity. The unit price shown is the price for each reference at a quantity of 1.
