1
Engine displacement
50
2
Model
PRIMAVERA
3
Year
2020
4
Trim
Primavera 50 25 km/h Euro 5
5
Parts Catalog
Reduction unit
6
Parts Diagram
Parts Catalog
Side cover - Spoiler
by
Saddle/seats
Reduction unit
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
1
Couvercle réducteur
1A017693
$255,47 Unit Price incl. VAT
2
Roulement radial
83045R
$2,59 Unit Price incl. VAT
3
Gasket ring
478498
$8,12 Unit Price incl. VAT
4
Circlip
006647
$1,10 Unit Price incl. VAT
5
Bearing 20x47x14
434735
$7,12 Unit Price incl. VAT
6
Shoe fulcrum pin
272921
$5,45 Unit Price incl. VAT
7
Screw w/ flange M8x45
B016805
$0,50 Unit Price incl. VAT
8
Washer 8.2x12x1
485703
$0,16 Unit Price incl. VAT
9
Hex socket screw M8x12
269755
$0,34 Unit Price incl. VAT
10
Reduction unit breather pipe assembly
CM162202
$24,21 Unit Price incl. VAT
11
Axe de roue avec pièces internes
1A017807
Not Available
12
Arbre de renvoi avec pièces internes
1A017808
Not Available
13
Roulement radial à billes
1A018024
$9,42 Unit Price incl. VAT
14
Roulement radial à billes
83047R
$8,41 Unit Price incl. VAT
15
Compensator ring
478197
$8,31 Unit Price incl. VAT
The diagrams are provided for reference only. If in doubt, our specialists are available to answer your questions. When adding a part to your cart, please make sure to select the desired quantity. The unit price shown is the price for one unit of each part number.
