1
Engine displacement
200
2
Model
RUNNER
3
Year
2002
4
Trim
Runner 200 VXR 4T
5
Parts Catalog
Driven pulley
6
Parts Diagram
Parts Catalog
by
Oil pump-oil pan
Driven pulley
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
1
Roller cage 20x29x18
82518R
$12,62 Unit Price incl. VAT
2
Snap ring
483226
$0,72 Unit Price incl. VAT
3
Radial bearing 17x30
483261
Not Available
3
Bearing 17x30x7
82753R
$19,17 Unit Price incl. VAT
4
Sec. fixed sheave, complete
833669
Not Available
4
Fixed driven half pulley
830580
$69,28 Unit Price incl. VAT
5
Guide pin L=12,5
828717
$0,34 Unit Price incl. VAT
6
Adjustable pulley, half
831027
$88,17 Unit Price incl. VAT
6
Sec. sliding sheave, complete
833672
Not Available
7
Gasket ring
431089
$2,55 Unit Price incl. VAT
8
Gasket
430585
$4,89 Unit Price incl. VAT
9
Pulley side cap
4310935
$9,79 Unit Price incl. VAT
9
Cup
833674
$9,70 Unit Price incl. VAT
10
Variator spring
825726
$5,64 Unit Price incl. VAT
10
Variator spring
833673
$8,77 Unit Price incl. VAT
11
Clutch side cap
487936
$5,73 Unit Price incl. VAT
12
Clutch, assy.
831030
$98,55 Unit Price incl. VAT
12
Clutch, assy.
840311
$168,75 Unit Price incl. VAT
13
Ring nut
433232
$2,31 Unit Price incl. VAT
14
Clutch drum
82751R
Not Available
14
Clutch drum
82517R
Not Available
14
Clutch drum
844049
Not Available
15
Pulley
831028
$109,43 Unit Price incl. VAT
15
Secondary pulley
82745R
Not Available
16
Nut M12x1.25
486324
$0,50 Unit Price incl. VAT
17
Spacer
827877
Not Available
18
Flat washer 22x12,1x1
274246
$0,34 Unit Price incl. VAT
19
Fan
482305
$9,99 Unit Price incl. VAT

Find the detailed :label GILERA PIAGGIO VESPA diagram on this page. This exploded view allows you to identify the various components you need to maintain your machine and quickly find their original GILERA PIAGGIO VESPA part number.


The diagrams are not contractually binding. If you have any doubts, our professionals are available to answer your questions. When adding a part to your cart, make sure to order the desired quantity. The unit price shown is the price for each reference at a quantity of 1.
