Stater - Electric starter for GILERA PIAGGIO VESPA Liberty 4T PTT E3 (A) from 2007

Fork/steering tube - Steering bearing unit

Stater - Electric starter

1

Starter motor

82611R

Not Available

2

VITE TESTA ESAGON.GAMBO INTER.FILETT.

031091

$0,17 Unit Price incl. VAT

2

VITE TE M6x20

018639

$0,16 Unit Price incl. VAT

3

GR.DI RINVIO AVVIAMENTO

82612R

$31,05 Unit Price incl. VAT

4

LEVA MESSA IN MOTO COMPL.

827632

$44,55 Unit Price incl. VAT

5

PROTEZIONE

286217

$5,45 Unit Price incl. VAT

6

Spring

286218

Not Available

7

RONDELLA PIANA 10,1X2,5

286219

$8,12 Unit Price incl. VAT

8

ANELLO

288041

$3,70 Unit Price incl. VAT

9

ANELLO ELASTICO

006416

$0,08 Unit Price incl. VAT

10

MOLLETTA

288673

$0,16 Unit Price incl. VAT

11

MOLLA RICHIAMO LEVA AVVIAMENTO

289495

$15,81 Unit Price incl. VAT

12

BUSSOLA

431205

$3,65 Unit Price incl. VAT

13

ROSETTA PIANA 16,3x23,8x0,6

433987

$2,99 Unit Price incl. VAT

14

PIGNONE M.IN MOTO COMPL.

483539

$7,62 Unit Price incl. VAT

15

TAMPONE SCONTRO SETTORE

830260

$6,30 Unit Price incl. VAT

16

kick starter axle

830284

Not Available

17

TAMPONE ELASTICO

830281

$5,53 Unit Price incl. VAT

18

Screw w/ flange M6x25

414837

Not Available

19

Screw w/ flange

436788

Not Available

20

RONDELLA ELASTICA ONDULATA 12x6,4x0,5

006976

$0,08 Unit Price incl. VAT

21

VITE TESTA ESAGON.FLANG. M6X10

969296

$0,16 Unit Price incl. VAT

Find the detailed Stater - Electric starter GILERA PIAGGIO VESPA diagram on this page. This exploded view allows you to identify the various components you need to maintain your machine and quickly find their original GILERA PIAGGIO VESPA part number.

The diagrams are not contractually binding. If you have any doubts, our professionals are available to answer your questions. When adding a part to your cart, make sure to order the desired quantity. The unit price shown is the price for each reference at a quantity of 1.
