1
Engine displacement
300
2
Model
BEVERLY
3
Year
2016
4
Trim
Beverly ie ABS E4
5
Parts Catalog
Brakes pipes - Calipers (ABS)
6
Parts Diagram
Parts Catalog
Flywheel magneto
by
Supply system
Brakes pipes - Calipers (ABS)
1A
1B
2A
2B
3
4
5
5
6
6
7A
7B
8
8
9
9
10
10
11
11
12
12
13
13
13
13
14
14
14
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
1A
ABS electro-hydraulic control unit
1C001631
$1 736,10 Unit Price incl. VAT
1B
ABS electro-hydraulic control unit
1C002747
$1 736,10 Unit Price incl. VAT
2A
ABS support bracket
667354
$37,35 Unit Price incl. VAT
2B
ABS support bracket
1C002817
$9,85 Unit Price incl. VAT
3
Screw w/ flange M6x16
B016777
$0,16 Unit Price incl. VAT
4
Spring plate M6
254485
$0,34 Unit Price incl. VAT
5
Hex screw M6x20
018639
$0,16 Unit Price incl. VAT
6
Washer
179575
$0,17 Unit Price incl. VAT
7A
Spacer
174969
$2,95 Unit Price incl. VAT
7B
Spacer
1C000253
$0,34 Unit Price incl. VAT
8
Pad
939278
$0,34 Unit Price incl. VAT
9
ABS unit - right brake pump pipe
667300
$73,57 Unit Price incl. VAT
9
ABS unit - right brake pump pipe
1C002796
Not Available
10
ABS unit - left brake pump pipe
1C002785
Not Available
10
ABS unit - left brake pump pipe
667301
$73,57 Unit Price incl. VAT
11
ABS unit brake pipe - front brake pin
1C002775
$66,99 Unit Price incl. VAT
11
ABS unit brake pipe - front brake pin
667302
$296,74 Unit Price incl. VAT
12
ABS unit - rear brake calliper flexible hose
1C002800
Not Available
12
ABS unit - rear brake calliper flexible hose
1C002518
$156,36 Unit Price incl. VAT
13
Special screw
1C002059R
$2,02 Unit Price incl. VAT
14
Gasket
127927
$0,25 Unit Price incl. VAT
15
(Heng Tong) Left brake pin
CM068313
$252,22 Unit Price incl. VAT
16
(Heng Tong) Brake pads couple
651253
$47,93 Unit Price incl. VAT
17
screw
598919
$2,27 Unit Price incl. VAT
18
Spring washer
709047
$0,08 Unit Price incl. VAT
19
Sensor ABS
859792
Not Available
20
screw
975805
$3,65 Unit Price incl. VAT
21
ABS support bracket sensor
667034
$26,74 Unit Price incl. VAT
22
screw M5x10
842908
Not Available
23
(Heng Tong) Right brake pin
CM068312
$238,95 Unit Price incl. VAT
24
(Heng Tong) Brake pads couple
665842
$43,20 Unit Price incl. VAT
25
Hex screw
665983
$3,65 Unit Price incl. VAT
26
Washer
012535
$0,08 Unit Price incl. VAT
27
Complete ABS sensor
1D0016745
$41,45 Unit Price incl. VAT
28
screw
975805
$3,65 Unit Price incl. VAT
29
Sensor bracket ABS
1C002567
Not Available
29
Sensor bracket ABS
1C001004
$20,04 Unit Price incl. VAT
30
Hex socket screw M8x40
149104
$0,51 Unit Price incl. VAT
31
Spring washer
709047
$0,08 Unit Price incl. VAT
32
Low self-locking nut
709052
$1,10 Unit Price incl. VAT
33
Lock-strap L=277
257134
$0,25 Unit Price incl. VAT
34
Hose clamp
675510
$1,80 Unit Price incl. VAT
35
Hose clamp
564629
$2,50 Unit Price incl. VAT
36
Spring washer 12x6,4x0,5
006976
$0,08 Unit Price incl. VAT
37
Hex socket screw M6x16
709099
$0,16 Unit Price incl. VAT
38
Clamp support bracket
1C002519
$8,32 Unit Price incl. VAT
39
Hose clamp
CM006901
$4,62 Unit Price incl. VAT
40
Hose clamp
217280
Not Available
41
Elastic spring
231590
$0,25 Unit Price incl. VAT
42
Hose clamp
667113
$6,38 Unit Price incl. VAT
43
Screw w/ flange M6x10
969296
$0,16 Unit Price incl. VAT
44
Hose clamp
667643
$1,18 Unit Price incl. VAT
45
Screw w/ flange M6x16
B016777
$0,16 Unit Price incl. VAT
46
Hose clamp
1C002899
$5,94 Unit Price incl. VAT

Find the detailed :label GILERA PIAGGIO VESPA diagram on this page. This exploded view allows you to identify the various components you need to maintain your machine and quickly find their original GILERA PIAGGIO VESPA part number.


The diagrams are not contractually binding. If you have any doubts, our professionals are available to answer your questions. When adding a part to your cart, make sure to order the desired quantity. The unit price shown is the price for each reference at a quantity of 1.
