Rear wheel

SWINGING ARM FOR VESPA GTS IE 2011

Brakes pipes - Calipers

Item numbers
Swinging arm VESPA VESPA-SCOOTER 300 GTS 2011 GTS ie
1
2
2
3
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
1
CHASSIS SIDE SWINGING ARM

56474R  

Contact
2
BUSH

598917  

Unit Price

3
ROLLER CAGE

600161  

Unit Price

4
HEX SOCKET SCREW M12X324

597914  

Unit Price

5
SPACER 290.00 MM

597857  

Unit Price

6
SELF LOCKING NUT M10

002440  

Unit Price

7
ENGINE SIDE SWINGING ARM

56331R  

Contact
8
ROLLER CAGE
SWING ARM BUSH X9

597374  

56127R

Unit Price

9
BUSH

597317  

Unit Price

10
SCREW M10X220

598237  

Unit Price

11
WASHER

266845  

Unit Price

12
SPACER 189.00 MM

CM067806  

Unit Price

13
NUT M12

271740  

Unit Price

14
HEX SOCKET SCREW M10X215

271779  

Unit Price

15
SPACER

599077  

Unit Price

16
SELF LOCKING NUT M10

002440  

Unit Price

17
CIRCLIP

006416  

Unit Price

18
SILENT-BLOCK

599250  

Unit Price

19
SPRING

599059  

Unit Price

20
SILENTBLOCK SUPPORT BRACKET

601815  

Unit Price

21
SILENT-BLOCK

272750  

Unit Price

22
BUSH

273460  

Unit Price

23
BOLT

031153  

Unit Price

24
WASHER
PLANE SPRING WASHER

709646  

012535

Unit Price

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from VESPA. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.

Find on this page all the original spare parts relating to the Swinging arm of your VESPA GTS ie of GTS. Let us know if you have any questions.

Genuine parts for VESPA GTS ie 2011

Engine Frame - Plastic parts - Coachwork Handlebars/Steering Suspensions - Wheels Braking system - Transmissions Electrical system

VESPA GTS ie 2011

Choose the exact model of your VESPA GTS 300 to access the different categories of genuine spare parts

300 GTS 2011 GTS ie

GTS ie

VESPA-SCOOTER GTS

Displacement: 300 cc
Year: 2011
