Displacement

Model

Year

Finish line

Parts catalogue

Parts diagram

Central cover - Footrests

FUEL TANK FOR VESPA LX 4T 3V IE 2012

Helmet huosing - Undersaddle

Item numbers
Fuel tank VESPA VESPA-SCOOTER 125 LX 2012 LX 4T 3V ie
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
1
INDICATOR FUEL LEVEL

CM025713  

Unit Price

2
PLUG

656022  

Unit Price

3
TANK COVER GASKET

656021  

Unit Price

4
FLAT WASHER 16X6, 5X1, 5

013880  

Unit Price

5
SPRING WASHER 6, 4X11, 8X1

016406  

Unit Price

6
HEX SCREW M6X20

018639  

Unit Price

7
COMPLETE FUEL PUMP ASSEMBLY

641136  

Unit Price

8
FUEL PUMP FILTER

639357  

Unit Price

9
TANK BREATHER PIPE

CM011904  

Unit Price

10
ELASTIC SPRING

672491  

Unit Price

11
PIPES/CABLES RETAINER SPRING

CM006913  

Unit Price

12
RING NUT

576546  

Unit Price

13
COMPLETE FUEL PIPE

674906  

Unit Price

14
FUEL TANK

655379  

Contact
15
SPRING PLATE M6

254485  

Unit Price

16
SPRING

CM013201  

Unit Price

17
LOCK-STRAP L=180MM

145298  

Unit Price

18
SAFETY VALVE

576748  

Unit Price

19
GASKET

656003  

Unit Price

20
HOSE CLAMP

CM001914  

Unit Price

21
SAE J30 PIPE R11-A O R12 1/4 L=920
HOSE

CM177902  

CM177910

Unit Price

22
HOSE CLAMP

CM001914  

Unit Price

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from VESPA. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.

Find on this page all the original spare parts relating to the Fuel tank of your VESPA LX 4T 3V ie of LX. Let us know if you have any questions.

Genuine parts for VESPA LX 4T 3V ie 2012

Engine Frame - Plastic parts - Coachwork Handlebars/Steering Suspensions - Wheels Braking system - Transmissions Electrical system

VESPA LX 4T 3V ie 2012

Choose the exact model of your VESPA LX 125 to access the different categories of genuine spare parts

125 LX 2012 LX 4T 3V ie

LX 4T 3V ie

VESPA-SCOOTER LX

Displacement: 125 cc
Year: 2012
