SUPPLY SYSTEM FOR VESPA GTV 4T E3 2006

Wheel huosing - Mudguard

Item numbers

FUEL PUMP
FUEL PUMP ASSY

CM120901

CM120903

$94,69

Unit Price

BRACKET

620050

$5,38

Unit Price

LOCK-STRAP L=277

257134

$0,25

Unit Price

FUEL PIPE
R MIXER FEEDING PIPE

CM004126

1R000160

$34,45

Unit Price

FUEL FILTER

270423

$10,67

Unit Price

FUEL PIPE
PIPE

CM006110

CM006116

$10,76

Unit Price

FUEL PIPE
R MIXER FEEDING PIPE

CM004103

1R000160

$34,45

Unit Price

TANK BREATHER PIPE Ø5X10 L.1060
PIPE (NOT METALLIC) D.5X10 L.1060

CM001422

CM001432

$11,50

Unit Price

HOSE CLAMP

CM002905

$0,42

Unit Price

FLEXIBLE SUPPORT

272842

$5,38

Unit Price

TEE UNION

828325

$1,57

Unit Price

TANK BREATHER PIPE Ø5X10 L.1060
PIPE (NOT METALLIC) D.5X10 L.1060

CM001429

CM001432

$11,50

Unit Price

METRIC SCREW M6X20

259830

$0,09

Unit Price

HOSE CLAMP

CM001901

$0,76

Unit Price

HOSE CLAMP

CM002907

$0,42

Unit Price

HOSE CLAMP

CM002905

$0,42

Unit Price

HOSE CLAMP

CM001911

$3,70

Unit Price

PIPE 3, 25X8X420

CM027916

$17,03

Unit Price

HOSE CLAMP

CM002905

$0,42

Unit Price

HOSE CLAMP

CM002905

$0,42

Unit Price

SPRING

CM013201

$0,40

Unit Price

NON RETURN SPRING

CM017803

$5,38

Unit Price

FUEL PUMP

639861

Contact

ELECTRICAL PUMP SUPPORT
ELECTRIC PUMP SUPPORT

624913

654047

$8,91

Unit Price

ELECTRICAL PUMP SUPPORT

652926

$12,40

Unit Price

HOSE CLAMP

CM001901

$0,76

Unit Price

FUEL PIPE
R MIXER FEEDING PIPE

CM004126

1R000160

$34,45

Unit Price

HOSE CLAMP

CM001901

$0,76

Unit Price

VALVE

654935

$12,97

Unit Price

FUEL PIPE
R MIXER FEEDING PIPE

CM004126

1R000160

$34,45

Unit Price

HOSE CLAMP

CM001901

$0,76

Unit Price

FUEL PIPE
R MIXER FEEDING PIPE

CM004103

1R000160

$34,45

Unit Price

FLEXIBLE SUPPORT

272842

$5,38

Unit Price

FUEL FILTER

270423

$10,67

Unit Price

FUEL PIPE
R MIXER FEEDING PIPE

CM004112

1R000160

$34,45

Unit Price

RETAINER CLAMP

487824

$0,33

Unit Price

SCREW W/ FLANGE M6X10

969296

$0,16

Unit Price

SHEET EDGE SPRING

CM013203

$0,67

Unit Price

LOCK-STRAP L=277

257134

$0,25

Unit Price

SCREW W/ FLANGE M6X16
FLANGED HEXAGONAL SCREW M6X16

434541

B016777

$0,16

Unit Price

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from VESPA. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
When adding a part to your cart, be careful to order the required quantity. Please note that the unit price indicated is the price for each part number in quantity 1.
Our parts are original and brand new spare parts of VESPA, to guarantee you quality and durable components. If you have any questions, we are here to help. Order your spare parts today and receive them directly at home!

All the genuine spare parts for the VESPA 2006
