Parts diagram

Head-Valves

OIL PUMP-ELECTRIC STARTER FOR PIAGGIO X9 EVOLUTION OTHER YEAR

Reduction Unit Cover

Item numbers
Oil Pump-Electric Starter PIAGGIO PIAGGIO-SCOOTER 500 X9 Other year X9 Evolution
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
15
16
17
18
19
20
1
SPACER

825737  

Unit Price

2
CHAIN TENSIONER ROD

827886  

Unit Price

3
SCREW M6X25
SCREW M6X25

830129  

B016797

Unit Price

4
OIL PUMP ASSEMBLY
OIL PUMP ASSY.

825281  

876225

Unit Price

5
CAMSHAFT CHAIN

827889  

Unit Price

6
SCREW W/ FLANGE

433477  

Unit Price

7
OIL BULHEAD

830064  

Unit Price

8
SCREW W/ FLANGE M5X16

830061  

Unit Price

9
GASKET
GASKET BETWEEN CRANKCASE AND OIL PUMP

828118  

847962

Unit Price

10
CHAIN TENSIONER SLIDING BLOCK

827882  

Unit Price

11
VIS BRIDE M6X25
FLANGED HEXAGONAL SCREW M6X25

414837  

B016774

Unit Price

12
STARTER MOTOR

82699R  

Unit Price

13
TORQUE LIMITER
TORQUE LIMITING DEVICE ASSY

8321174  

876835

Unit Price

14
OIL FILTER

826033  

Unit Price

15
OIL FILTER PLUG

826165  

Unit Price

16
O-RING 31, 47X1, 78

285536  

Unit Price

17
GROUND CABLE

584843  

Unit Price

18
SCREW M6X12

031086  

Unit Price

19
SPRING WASHER 6, 4X11, 8X1

016406  

Unit Price

20
O-RING 20, 35X1, 78

288474  

Unit Price

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from PIAGGIO. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
When adding a part to your cart, be careful to order the required quantity. Please note that the unit price indicated is the price for each part number in quantity 1.
Our parts are original and brand new spare parts of PIAGGIO, to guarantee you quality and durable components. If you have any questions, we are here to help. Order your spare parts today and receive them directly at home!

Genuine parts for PIAGGIO X9 Evolution Other year

Electrical equipment Engine Handlebars Transmissions Suspensions-Wheels Chassis

PIAGGIO X9 Evolution Other year

All the genuine spare parts for the PIAGGIO Other year

500 X9 Other year X9 Evolution

X9 Evolution

PIAGGIO-SCOOTER X9

Displacement: 500 cc
Year: Other year
