BRAKES PIPES - CALIPERS (ABS) FOR PIAGGIO X10 4T 4V I.E. E3 2013

Transmissions

Item numbers

RH BRAKE CALIPER

CM068316

Contact

BRAKE PADS COUPLE

668017

$70,78

Unit Price

BRAKE SUPP. PLATE PIN

666139

$5,33

Unit Price

LH BRAKE CALIPER

CM068319

$105,61

Unit Price

(HENG TONG) BRAKE PADS COUPLE

651253

$47,93

Unit Price

BRAKE SUPP. PLATE PIN

666139

$5,33

Unit Price

TORX CONVEX BIG END SCREW

651297

$4,82

Unit Price

SPRING WASHER

709047

$0,05

Unit Price

ABS ELECTRO-HYDRAULIC CONTROL UNIT

667981

Contact

ABS ELECTRO-HYDRAULIC CONTROL UNIT

667999

Contact

SUPPORT CLAMP

668264

$7,44

Unit Price

ABS SUPPORT BRACKET WITH I.P.

668058

$17,41

Unit Price

HEX SCREW M6X20

018639

$3,30

Unit Price

SPACER

174969

$2,95

Unit Price

WASHER

179575

$2,95

Unit Price

PAD

939278

$4,32

Unit Price

SCREW W/ FLANGE M6X14

874554

$0,15

Unit Price

SCREW W/ FLANGE

598839

$0,09

Unit Price

CONICAL WASHER

834951

$0,15

Unit Price

ABS UNIT RIGHT BRAKE PUMP PIPE

668215

$35,94

Unit Price

ABS UNIT BRAKE PIPE - FRONT BRAKE PIN

668216

$34,32

Unit Price

ABS UNIT - LEFT BRAKE PUMP PIPE

668214

$34,55

Unit Price

ABS BRAKE PIPE - VALVE

668217

$33,60

Unit Price

PRESSURE ADJUSTING VALVE

CM086101

$114,25

Unit Price

HEX SOCKET SCREW M6X16

709099

$0,16

Unit Price

SPRING WASHER 12X6, 4X0, 5

006976

$3,38

Unit Price

OIL PIPE SCREW M10X18

265451

$1,25

Unit Price

GASKET

127927

$0,09

Unit Price

BRAKE PIPE (VALVE-CALIPER)

668231

$30,22

Unit Price

REAR BRAKE PIPE

668692

$92,87

Unit Price

ÉTRIER DE FREIN D
RIGHT CALIPER

CM068318

CM294406

$92,92

Unit Price

(HENG TONG) BRAKE PADS COUPLE

665842

$43,20

Unit Price

BRAKE SUPP. PLATE PIN

666139

$5,33

Unit Price

HEX SCREW

668136

$0,88

Unit Price

WASHER
PLANE SPRING WASHER

709646

012535

$2,95

Unit Price

PARKING BRAKE CALLIPER

CM084602

$140,27

Unit Price

BRAKE PADS COUPLE

668541

$39,30

Unit Price

HEX SOCKET SCREW

826298

$3,38

Unit Price

SPRING WASHER

709047

$0,05

Unit Price

HOSE CLAMP

598795

$8,01

Unit Price

SCREW W/ FLANGE M6X14

874554

$0,15

Unit Price

SCREW W/ FLANGE M6X16
FLANGED HEXAGONAL SCREW M6X16

434541

B016777

$3,65

Unit Price

HOSE CLAMP

668866

$2,59

Unit Price

HOSE CLAMP

668303

$7,54

Unit Price

HOSE CLAMP

667156

$0,77

Unit Price

HOSE CLAMP

666047

$0,92

Unit Price

HOSE CLAMP
PIPE RETAINING CLIP WITH RUBBER SLEEVE

623743

675510

$5,20

Unit Price

LOCK-STRAP L=180MM

145298

$3,38

Unit Price

SPRING

CM013201

$4,46

Unit Price

NON RETURN SPRING

CM006902

$5,38

Unit Price

SPRING

179013

$4,82

Unit Price

HEX SCREW M8X22

031119

$3,65

Unit Price

COMPLETE COVER

651318

Contact

BUSHING

650884

$2,20

Unit Price

HEX SOCKET SCREW M6X12

274369

$0,09

Unit Price

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from PIAGGIO. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
When adding a part to your cart, be careful to order the required quantity. Please note that the unit price indicated is the price for each part number in quantity 1.
Our parts are original and brand new spare parts of PIAGGIO, to guarantee you quality and durable components. If you have any questions, we are here to help. Order your spare parts today and receive them directly at home!
