MAIN CABLE HARNESS FOR PIAGGIO MP3 500 SPORT 2012

Rear headlamps - Turn signal lamps

Item numbers

CABLE HARNESS

1D000096

$542,47

Unit Price

CABLE HARNESS

642784

Contact

CABLE HARNESS
WIRING HARNESS

641323

642598

$510,79

Unit Price

FUSE 7, 5A

252945

$0,29

Unit Price

FUSE 15A

290860

$0,29

Unit Price

FUSE 20A

580561

$0,29

Unit Price

REED FUSE 3A

582930

$4,32

Unit Price

FUSE 30A

CM225730

$6,53

Unit Price

CONNECTOR SPRING

584520

$5,38

Unit Price

SPRING CLAMP

577594

$4,82

Unit Price

LOCK-STRAP L=180MM

145298

$3,38

Unit Price

AMBIENT TEMPERATURE SENSOR

581142

Contact

RIGHT SPEED SENSOR CABLE ASSEMBLY

642549

$35,36

Unit Price

SCREW W/ FLANGE M6X10

969296

$0,09

Unit Price

HOSE CLAMP

573918

$3,65

Unit Price

LEFT SPEED SENSOR CABLE ASSEMBLY

642550

$35,36

Unit Price

TBCIC SCREW

270793

$2,74

Unit Price

WASHER

013963

$2,95

Unit Price

HOSE CLAMP

271477

$3,65

Unit Price

LOCK-STRAP L=277

257134

$0,09

Unit Price

CLAMP

D9004461193

1E003352

$5,37

Unit Price

SPRING CLAMP

577594

$4,82

Unit Price

SPRING

CM013201

$4,46

Unit Price

PIPES/CABLES RETAINER SPRING

CM013202

$5,10

Unit Price

LOCK-STRAP L=277

257134

$0,09

Unit Price

LOCK-STRAP L=180MM

145298

$3,38

Unit Price

METALLIC CLAMP

640590

$5,53

Unit Price

WASHER

012528

$2,95

Unit Price

SELF-TAPPING SCREW

430264

$0,09

Unit Price

CONNECTOR SPRING

584520

$5,38

Unit Price

SELF-TAPPING SCREW

430264

$0,09

Unit Price

HEX SCREW M6X18

031089

$2,95

Unit Price

HOSE CLAMP

638792

$4,82

Unit Price

SPRING WASHER 6, 4X11, 8X1

016406

$3,65

Unit Price

SCREW W/ FLANGE M6X16

B016777

$3,65

Unit Price

CLAMP SUPPORT BRACKET

642063

$18,75

Unit Price

GUARD

CM077703

$4,32

Unit Price

WASHER

012528

$2,95

Unit Price

TRI/LOBED HEXAGONAL SELF-TAPPING SCREW

641204

$0,19

Unit Price

FLAT WASHER 6, 4X12X1

003056

$3,65

Unit Price

SPRING WASHER 6, 4X11, 8X1

016406

$3,65

Unit Price

MOUNTING FOR USB

1B0003000000C

$2,90

Unit Price

SOCKET USB

643277

Contact

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from PIAGGIO. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.

Find on this page all the original spare parts relating to the Main cable harness of your PIAGGIO MP3 500 Sport of MP3. Let us know if you have any questions.
