MAIN CABLE HARNESS FOR PIAGGIO BEVERLY CRUISER E3 2011

Rear headlamps - Turn signal lamps

Item numbers

FRAME HARNESS

640540

$361,79

Unit Price

FUSE 7, 5A

252945

$0,29

Unit Price

FUSE 15A

290860

$0,29

Unit Price

REED FUSE 10A

292507

$0,29

Unit Price

FUSE 30A
FUSE

581440

CM225730

$6,53

Unit Price

FUSE HOLDER

581190

$7,23

Unit Price

PLUG

581191

$5,38

Unit Price

INSTRUMENT SUPPORT

639632

$4,98

Unit Price

SPRING PLATE

CM017409

$3,65

Unit Price

SCREW M4, 2X13

259349

$2,74

Unit Price

TBCIC SCREW

270793

$2,74

Unit Price

WASHER

012528

$2,95

Unit Price

SELF-TAPPING SCREW

430264

$0,09

Unit Price

SPRING WASHER 6, 4X11, 8X1

016406

$3,65

Unit Price

FUSEBOX TERMINAL BLOCK

584225

$9,22

Unit Price

SPRING

140435

$0,05

Unit Price

ELASTIC SPRING

231590

$2,66

Unit Price

LOCK-STRAP L=180MM

145298

$3,38

Unit Price

COLLIER
REMOVABLE CLAMP

217280

298729

$3,65

Unit Price

COVER

584226

Contact

LOCK-STRAP L=277

257134

$0,09

Unit Price

HOSE CLAMP

271477

$3,65

Unit Price

FLEXIBLE SUPPORT

291017

$19,68

Unit Price

CLAMP SUPPORT BRACKET

639456

$5,38

Unit Price

LOCK-STRAP L=180MM

145298

$3,38

Unit Price

METALLIC CLAMP

640590

$5,53

Unit Price

CONNECTORS SUPPORT BRACKET

640597

Contact

TCCIC M5X16
CROSS SLOTTED SCREW WITH CYLINDER HEAD

015935

1A003109

$3,65

Unit Price

SPRING WASHER 8, 5X5, 1X1, 5

016405

$2,95

Unit Price

ELECTRONIC CONTROL UNIT

584960

Contact

SCREW W/ FLANGE M6X16
FLANGED HEXAGONAL SCREW M6X16

434541

B016777

$3,65

Unit Price

NUT M6

020106

$3,38

Unit Price

SPRING WASHER 6, 4X11, 8X1

016406

$3,65

Unit Price

HOSE CLAMP

307166

$2,95

Unit Price

CAP

583971

$8,54

Unit Price

PIPES/CABLES RETAINER SPRING

CM013202

$5,10

Unit Price

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from PIAGGIO. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
When adding a part to your cart, be careful to order the required quantity. Please note that the unit price indicated is the price for each part number in quantity 1.
Our parts are original and brand new spare parts of PIAGGIO, to guarantee you quality and durable components. If you have any questions, we are here to help. Order your spare parts today and receive them directly at home!
