Displacement

Model

Year

Finish line

Parts catalogue

Parts diagram

Front wheel

REAR SUSPENSION - SHOCK ABSORBER / S FOR PIAGGIO X10 4T 4V I.E. E3 2014

Rear wheel

Item numbers
Rear suspension - Shock absorber/s PIAGGIO PIAGGIO-SCOOTER 350 X10 2014 X10 4T 4V I.E. E3
1
2
2
3
3
4
5
5
6
6
7
7
8
9
10
11
12
13
14
15
16
17
18
1
COMPLETE REAR SHOCK ABSORBER

58607R  

Unit Price

2
SCREW W/ FLANGE

598838  

Unit Price

3
SELF LOCKING NUT M10

002440  

Unit Price

4
RIGHT REAR SHOCK ABSORBER CONNECTION BRACKET

666355  

Unit Price

5
SCREW M10X40

030097  

Unit Price

6
WASHER
PLANE SPRING WASHER

709646  

012535

Unit Price

7
SHOCK ABSORBER BUSH

AP8161031  

Unit Price

8
HEX SOCKET SCREW M8X50

844483  

Unit Price

9
SPRING WASHER

709047  

Unit Price

10
LEFT REAR SHOCK ABSORBER CONNECTION BRACKET

667728  

Unit Price

11
SPRING WASHER 16X8, 2X2, 2

834187  

Unit Price

12
SCREW

030074  

Unit Price

13
SPRING WASHER

709047  

Unit Price

14
BRACCIO SOSPENSIONE DX COMPLETO

B017641  

Unit Price

15
CIRCLIP

006647  

Unit Price

16
BALL BEARING

82545R  

Unit Price

17
HEX SOCKET SCREW

845590  

Unit Price

18
FLAT WASHER 15X8, 4X1, 5
FLAT WASHER

013776  

003058

Unit Price

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from PIAGGIO. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
When adding a part to your cart, be careful to order the required quantity. Please note that the unit price indicated is the price for each part number in quantity 1.
Our parts are original and brand new spare parts of PIAGGIO, to guarantee you quality and durable components. If you have any questions, we are here to help. Order your spare parts today and receive them directly at home!

Genuine parts for PIAGGIO X10 4T 4V I.E. E3 2014

Engine Frame - Plastic parts - Coachwork Handlebars/Steering Suspensions - Wheels Braking system - Transmissions Electrical system

PIAGGIO X10 4T 4V I.E. E3 2014

All the genuine spare parts for the PIAGGIO 2014

350 X10 2014 X10 4T 4V I.E. E3

X10 4T 4V I.E. E3

PIAGGIO-SCOOTER X10

Displacement: 350 cc
Year: 2014
