REAR SUSPENSION - SHOCK ABSORBER / S FOR PIAGGIO BV 4T 4V IE E3 ABS 2015

Rear wheel

Item numbers
Rear suspension - Shock absorber/s PIAGGIO PIAGGIO-SCOOTER 350 BV 2015 BV 4T 4V ie E3 ABS
1
1
2
2
3
4
5
6
7
7
8
9
10
10
11
12
13
14
15
15
16
16
1
COMPLETE REAR SHOCK ABSORBER

58613R  

Unit Price

2
SCREW W/ FLANGE M10

268158  

Unit Price

3
SELF LOCKING NUT M10

002440  

Unit Price

4
SIL.BLOCK

880343  

Unit Price

5
SHOCK ABSORBER CONNECTION BRACKET

666678  

Unit Price

6
SIL.BLOCK

880343  

Unit Price

7
SCREW

030074  

Unit Price

8
WASHER
PLANE SPRING WASHER

709646  

012535

Unit Price

9
HEX SOCKET SCREW M8X50

844483  

Unit Price

10
FLAT WASHER 15X8, 4X1, 5
FLAT WASHER

013776  

003058

Unit Price

11
SPRING WASHER

709047  

Unit Price

12
RIGHT SUSPENSION ARM

880389  

Unit Price

13
CIRCLIP

006647  

Unit Price

14
BALL BEARING

82545R  

Unit Price

15
HEX SOCKET SCREW

845590  

Unit Price

16
SPRING WASHER 16X8, 2X2, 2

834187  

Unit Price

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from PIAGGIO. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.

Find on this page all the original spare parts relating to the Rear suspension - Shock absorber/s of your PIAGGIO BV 4T 4V ie E3 ABS of BV. Let us know if you have any questions.
