REAR SUSPENSION - SHOCK ABSORBER / S FOR PIAGGIO CARNABY 4T E3 2007

Rear wheel

Item numbers
Rear suspension - Shock absorber/s PIAGGIO PIAGGIO-SCOOTER 200 CARNABY 2007 Carnaby 4T E3
1
2
3
4
5
6
7
7
8
8
9
10
11
12
13
13
14
15
16
1
FLAT WASHER 15X8, 4X1, 5
FLAT WASHER

013776  

003058

Unit Price

2
SPRING WASHER

709047  

Unit Price

3
HEX SOCKET SCREW

826298  

Unit Price

4
SUSPENSION ARM

599867  

Unit Price

5
CIRCLIP

006647  

Unit Price

6
BALL BEARING

82545R  

Unit Price

7
SCREW W/ FLANGE M8X40

AP8152290  

Unit Price

8
SELF-LOCKING NUT M8

AP8152300  

Unit Price

9
SHOCK ABSORBER SUPPORT

AP8134974  

Unit Price

10
WASHER 10, 5X21X2*

AP8150020  

Unit Price

11
HEX SOCKET SCREW M10X45

AP8150038  

Unit Price

12
SCREW W/ FLANGE M8X50

AP8152292  

Unit Price

13
SELF-LOCKING NUT M8

AP8152300  

Unit Price

14
SELF-LOCKING NUT

AP8152301  

Unit Price

15
SHOCK ABSORBER BUSH

AP8161031  

Unit Price

16
REAR SHOCK ABSORBER CPL.
REAR SHOCK ABSORB. ASSY

56407R  

649423

Unit Price

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from PIAGGIO. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.

Find on this page all the original spare parts relating to the Rear suspension - Shock absorber/s of your PIAGGIO Carnaby 4T E3 of CARNABY. Let us know if you have any questions.
