CYLINDER-PISTON-WRIST PIN, ASSY FOR PIAGGIO HEXAGON GTX OTHER YEAR

Driven pulley

Item numbers
Cylinder-piston-wrist pin, assy PIAGGIO PIAGGIO-SCOOTER 180 HEXAGON Other year Hexagon GTX
1
1
1
2
3
4
5
6
6
6
6
7
8
9
1
CYLINDER BASE GASKET 0, 6 MM
CRANKCAS/CYLINDER PACKING

828147  

875113

Unit Price

1
CYLINDER BASE GASKET 0, 4 MM
CRANKASE/CYLINDER PACKING

828146  

875112

Unit Price

1
CYLINDER BASE GASKET 0, 8 MM
CRANKCAS/CYLINDER PACKING

828148  

875114

Unit Price

2
PISTON PIN

825172  

Contact
3
STOP RING

239455  

Unit Price

4
OIL SCRAPER RING

487884  

Contact
5
STUD BOLT M6

239397  

Unit Price

6
PIST.-WRIST PIN ASSY.

8286975001  

Contact
6
PIST.-WRIST PIN ASSY.

8286975002  

Contact
6
PIST.-WRIST PIN ASSY.

8286975003  

Contact
6
PIST.-WRIST PIN ASSY.

8286975004  

Contact
7
CYL.UNIT

828696  

Contact
8
PISTON RING

825489  

Unit Price

9
OIL SCRAPER RING

487883  

Contact
Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from PIAGGIO. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.

Find on this page all the original spare parts relating to the Cylinder-piston-wrist pin, assy of your PIAGGIO Hexagon GTX of HEXAGON. Let us know if you have any questions.

Genuine parts for PIAGGIO Hexagon GTX Other year

Electrical equipment Engine Handlebars Suspensions-Wheels Chassis

PIAGGIO Hexagon GTX Other year

Choose the exact model of your PIAGGIO HEXAGON 180 to access the different categories of genuine spare parts

180 HEXAGON Other year Hexagon GTX

Hexagon GTX

PIAGGIO-SCOOTER HEXAGON

Displacement: 180 cc
Year: Other year
