CRANKSHAFT

CDI MAGNETO ASSY FOR PIAGGIO MEDLEY 4T IE ABS 2017

Crankcase cover - Crankcase cooling

Item numbers
Cdi magneto assy PIAGGIO PIAGGIO-SCOOTER 150 MEDLEY 2017 Medley 4T ie ABS
1
2
3
4
5
6
7
8
9
10
11
1
STATOR COMPLET
COMPLETE STATOR

1A002542  

1A013291

Unit Price

2
VIS TÊTE CYLINDRIQUE À SIX PANS CREUX

1A005637  

Unit Price

3
SCREW

1A003477  

Unit Price

4
SCREW

1A003477  

Unit Price

5
ROTOR COMPLET

1A006220  

Unit Price

6
RONDELLE PLATE 32X16, 1X2.5

1A003712  

Unit Price

7
RESSORT À GODET

B018464  

Unit Price

8
ÉCROU HEXAGONAL M16X1, 25

B015996  

Unit Price

9
VENTILATEUR

1A006071  

Unit Price

10
SCREW

1A004975  

Unit Price

11
TRANSMISSION KEY
KEY

B015997  

000097

Unit Price

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from PIAGGIO. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.

Find on this page all the original spare parts relating to the Cdi magneto assy of your PIAGGIO Medley 4T ie ABS of MEDLEY. Let us know if you have any questions.
