CYLINDER-PISTON-WRIST PIN, ASSY FOR PIAGGIO X9 EVOLUTION OTHER YEAR

Driven pulley

Item numbers
Cylinder-piston-wrist pin, assy PIAGGIO PIAGGIO-SCOOTER 125 X9 Other year X9 Evolution
1
1
1
2
3
4
4
4
4
5
5
5
5
6
6
6
6
6
6
6
6
6
6
6
7
8
8
8
8
1
CYLINDER BASE GASKET 0, 6 MM
CRANKCAS/CYLINDER PACKING

828147  

875113

Unit Price

1
CYLINDER BASE GASKET 0, 4 MM
CRANKASE/CYLINDER PACKING

828146  

875112

Unit Price

1
CYLINDER BASE GASKET 0, 8 MM
CRANKCAS/CYLINDER PACKING

828148  

875114

Unit Price

2
PISTON PIN

482335  

Unit Price

3
SNAP RING

963486  

Unit Price

4
OIL SCRAPER RING D.57X2, 5

485914  

Unit Price

4
SCRAPER RING

487995  

Contact
4
SCRAPER RING

487999  

Contact
4
SCRAPER RING

488003  

Unit Price

5
OIL SCRAPER RING D.57X1

486362  

Unit Price

5
OIL SCRAPER RING

487996  

Unit Price

5
OIL SCRAPER RING

488004  

Contact
5
OIL SCRAPER RING

825029  

Unit Price

6
PISTON-WRIST PIN ASSY.

828463  

Contact
6
PISTON-WRIST PIN ASSY.

828464  

Contact
6
PISTON-WRIST PIN ASSY.

828465  

Contact
6
PISTON-WRIST PIN ASSY.

8284665002  

Contact
6
PISTON-WRIST PIN ASSY.

8284665004  

Contact
6
ERROR

8286665001  

Contact
6
ERROR

8286665002  

Contact
6
ERROR

8286665003  

Contact
6
ERROR

8286665004  

Contact
6
PISTON-PIST. PIN-RINGS GROUP (S. PARTS)
PISTON-PIST. PIN-RINGS GROUP (S. PARTS)

8284665001  

1A0077850A

Unit Price

6
PISTON-PIST. PIN-RINGS GROUP (S. PARTS)
PISTON-PIST. PIN-RINGS GROUP (S. PARTS)

8284665003  

1A0077850C

Unit Price

7
CYLINDER, ASSY.

830051  

Contact
8
COMPRESSION RING D.57X1

485779  

Unit Price

8
GASKET RING

487994  

Contact
8
GASKET RING

487998  

Contact
8
GASKET RING

488002  

Contact
