Displacement

Model

Year

Finish line

Parts catalogue

Parts diagram

Stand / s

COOLING SYSTEM FOR PIAGGIO MP3 YOURBAN ERL 2013

Wheel huosing - Mudguard

Item numbers
Cooling system PIAGGIO PIAGGIO-SCOOTER 125 MP3 2013 MP3 YOUrban ERL
1
2
3
4
5
6
7
8
9
9
10
11
11
11
11
12
12
13
14
15
16
17
18
19
20
20
21
21
22
23
24
25
25
26
27
28
29
30
30
31
32
1
WATER COOLER

657340  

Unit Price

2
PIN

AP8121464  

Unit Price

3
MUDGUARD BUSH

AP8221218  

Unit Price

4
SPACER

AP8125848  

Unit Price

5
WASHER 4, 5X12X1

016670  

Unit Price

6
SELF-TAP SCREW M3X20

258146  

Unit Price

7
SCREW

259577  

Unit Price

8
ELECTRIC FAN

642283  

Unit Price

9
LOWER RUBBER

258904  

Unit Price

10
AIR DUCT

657344  

Unit Price

11
METRIC SCREW M6X22

CM179201  

Unit Price

12
SPRING PLATE M6

254485  

Unit Price

13
COOLANT TANK

657341  

Unit Price

14
EXPANSION TANK PLUG

623673  

Unit Price

15
LOCK-STRAP L=277

257134  

Unit Price

16
CYLINDRICAL CABLE GROMMET

576565  

Unit Price

17
SELF TAPPING SCREW D4.2X16

CM178601  

Unit Price

18
SPRING PLATE

CM017410  

Unit Price

19
HOSE CLAMP

CM001903  

Unit Price

20
RADIATOR BREATHER PIPE

657337  

Unit Price

21
HOSE CLAMP

CM001904  

Unit Price

22
EXP.TNK-RAD. HOSE

657336  

Unit Price

23
HOSE CLAMP

CM001907  

Unit Price

24
PUMP-RADIATOR PIPE FITTING

672116  

Contact
25
PIPES/CABLES RETAINER SPRING

CM006903  

Unit Price

26
HOSE CLAMP

CM001922  

Unit Price

27
HOSE CLAMP

CM001907  

Unit Price

28
WATER COOLER-HEAD TUBE

657339  

Unit Price

29
NON RETURN SPRING

CM006902  

Unit Price

30
PIPES/CABLES RETAINER SPRING

CM006903  

Unit Price

31
HOSE CLAMP

CM001922  

Unit Price

32
ELASTIC SPRING

672491  

Unit Price

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from PIAGGIO. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.

Find on this page all the original spare parts relating to the Cooling system of your PIAGGIO MP3 YOUrban ERL of MP3. Let us know if you have any questions.

Genuine parts for PIAGGIO MP3 YOUrban ERL 2013

Engine Frame - Plastic parts - Coachwork Handlebars/Steering Suspensions - Wheels Braking system - Transmissions Electrical system

PIAGGIO MP3 YOUrban ERL 2013

Choose the exact model of your PIAGGIO MP3 125 to access the different categories of genuine spare parts

125 MP3 2013 MP3 YOUrban ERL

MP3 YOUrban ERL

PIAGGIO-SCOOTER MP3

Displacement: 125 cc
Year: 2013
