Displacement

Model

Year

Finish line

Parts catalogue

Parts diagram

Flywheel magneto cover - Oil filter

HEAD UNIT - VALVE FOR PIAGGIO MP3 YOURBAN ERL 2012

Oil pump

Item numbers
Head unit - Valve PIAGGIO PIAGGIO-SCOOTER 125 MP3 2012 MP3 YOUrban ERL
1
2
3
4
5
6
6
7
7
8
8
9
9
10
10
11
11
11
12
13
14
15
16
16
17
18
19
20
21
22
1
CYLINDER HEAD
CYLINDER HEAD

8778015  

8778016

Unit Price

2
STUD BOLT M7

435629  

Unit Price

3
EXHAUST PIPE GASKET

480853  

Unit Price

4
SOUPAPE ÉCHAPPEMENT
EXHAUST VALVE

873114  

873839

Unit Price

5
VALVE, IN
INTAKE VALVE

872999  

873809

Unit Price

6
LOWER CAP

483711  

Unit Price

7
VALVE GASKET RING

436438  

Unit Price

8
VALVE SPRING

875140  

Unit Price

9
UPPER CAP

483914  

Unit Price

10
VALVE HALF-CONE

285846  

Unit Price

11
SPACER WASHER 0, 4 MM

CM159801  

Unit Price

11
SPACER WASHER 0, 8 MM

CM159802  

Unit Price

11
SPACER WASHER 1, 2 MM

CM159803  

Unit Price

12
BULBE DE TEMPÉRATURE D’EAU
WATER TEMPERATURE SENSOR

640485  

1A021287R

Unit Price

13
SCREW W/ FLANGE

485603  

Unit Price

14
CAP NUT

832870  

Unit Price

15
CYLINDER HEAD GASKET 0, 3 MM

876625  

Unit Price

16
HEX SOCKET SCREW M5X20

845753  

Contact
16
TORX SCREW M5X20

B016808  

Unit Price

17
WATER OUTLET UNION

B013679  

Contact
18
BLEED SCREW

B013677  

Unit Price

19
WATER THERMOSTAT

82951R  

Unit Price

20
PLUG M6X25
THREADED TAPER

877432  

8774325

Unit Price

21
LOCATING DOWEL Ø7, 5X12

277916  

Unit Price

22
LOCATING DOWEL
REFERENCE DOWEL

478115  

B015957

Unit Price

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from PIAGGIO. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.

Find on this page all the original spare parts relating to the Head unit - Valve of your PIAGGIO MP3 YOUrban ERL of MP3. Let us know if you have any questions.

Genuine parts for PIAGGIO MP3 YOUrban ERL 2012

Engine Frame - Plastic parts - Coachwork Handlebars/Steering Suspensions - Wheels Braking system - Transmissions Electrical system

PIAGGIO MP3 YOUrban ERL 2012

Choose the exact model of your PIAGGIO MP3 125 to access the different categories of genuine spare parts

125 MP3 2012 MP3 YOUrban ERL

MP3 YOUrban ERL

PIAGGIO-SCOOTER MP3

Displacement: 125 cc
Year: 2012
