Parts catalogue

Parts diagram

Front headlamps - Turn signal lamps

MAIN CABLE HARNESS FOR PIAGGIO MP3 IE 2009

Rear headlamps - Turn signal lamps

Item numbers

CABLE HARNESS

641593

$516,14

Unit Price

FUSE 7, 5A

252945

$0,29

Unit Price

FUSE 15A

290860

$0,29

Unit Price

FUSE 20A

580561

$0,29

Unit Price

FUSE 30A
FUSE

496404

CM225730

$6,53

Unit Price

CONNECTOR SPRING

584520

$5,38

Unit Price

BRACKET

639843

$6,30

Unit Price

SCREW W/ FLANGE

484123

$0,05

Unit Price

WASHER

012528

$2,95

Unit Price

RIGHT SPEED SENSOR CABLE ASSEMBLY
RIGHT SPEED SENSOR WIRING HARNESS

640959

642549

$35,36

Unit Price

SCREW W/ FLANGE M6X16
FLANGED HEXAGONAL SCREW M6X16

434541

B016777

$3,65

Unit Price

SCREW W/ FLANGE M6X10

969296

$0,09

Unit Price

HOSE CLAMP

573918

$3,65

Unit Price

LEFT SPEED SENSOR CABLE ASSEMBLY
LEFT SPEED SENSOR WIRING HARNESS

640960

642550

$35,36

Unit Price

TBCIC SCREW

270793

$2,74

Unit Price

WASHER

013963

$2,95

Unit Price

HOSE CLAMP

271477

$3,65

Unit Price

CLAMP

D9004461193

1E003352

$5,37

Unit Price

LOCK-STRAP L=277

257134

$0,09

Unit Price

PIPES/CABLES RETAINER SPRING L=16

CM006907

$5,38

Unit Price

SPRING

CM013201

$4,46

Unit Price

LOCK-STRAP L=277

257134

$0,09

Unit Price

LOCK-STRAP L=180MM

145298

$3,38

Unit Price

PIPES/CABLES RETAINER SPRING

CM006903

$5,38

Unit Price

SELF-TAPPING SCREW

430264

$0,09

Unit Price

AMBIENT TEMPERATURE SENSOR

581142

Contact

ELASTIC SPRING

231590

$2,66

Unit Price

BRACKET

641192

$2,85

Unit Price

HEX SCREW M6X18

031089

$2,95

Unit Price

GROUND CABLE

584843

$9,18

Unit Price

TRI/LOBED HEXAGONAL SELF-TAPPING SCREW

641204

$0,19

Unit Price

SPRING WASHER 6, 4X11, 8X1

016406

$3,65

Unit Price

FLAT WASHER 6, 4X12X1

003056

$3,65

Unit Price

WASHER 5, 2X15X1, 5

224664

$0,77

Unit Price

SCREW W/ FLANGE

484123

$0,05

Unit Price

CONNECTOR SPRING

584520

$5,38

Unit Price

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from PIAGGIO. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.

Find on this page all the original spare parts relating to the Main cable harness of your PIAGGIO MP3 ie of MP3. Let us know if you have any questions.
