Parts diagram

Front headlamps - Turn signal lamps

MAIN CABLE HARNESS FOR PIAGGIO FLY 4T/3V IE E3 LEM 2013

Rear headlamps - Turn signal lamps

Item numbers
Main cable harness PIAGGIO PIAGGIO-SCOOTER 125 FLY 2013 Fly 4T/3V ie E3 LEM
1
2
3
4
5
6
6
7
8
9
10
11
12
13
14
15
16
16
17
18
19
20
21
22
23
1
CABLE HARNESS

680196  

Unit Price

2
REED FUSE 10A

292507  

Unit Price

3
FUSE 7, 5A

252945  

Unit Price

4
REED FUSE 5A

293256  

Unit Price

5
FUSE HOLDER

642405  

Unit Price

6
FUSE 20A

580561  

Unit Price

6
FUSE 30A

CM225730  

Unit Price

7
LOCK-STRAP L=277

257134  

Unit Price

8
CAP

292577  

Contact
9
CAP

581061  

Unit Price

10
PIPES/CABLES RETAINER SPRING

CM013202  

Unit Price

11
CAP

583971  

Unit Price

12
PLUG CONNECT DIAGNOS ECU

582928  

Unit Price

13
SHEET EDGE SPRING

CM013203  

Unit Price

14
PLUGS SPRING

641599  

Unit Price

15
LOCK-STRAP L=180MM

145298  

Unit Price

16
NON RETURN SPRING L=12

CM006905  

Unit Price

16
NON RETURN SPRING L=23

CM006908  

Unit Price

17
SCREW M16X16

015558  

Unit Price

18
TRI/LOBED HEXAGONAL SELF-TAPPING SCREW

641204  

Unit Price

19
SPRING WASHER 6, 4X11, 8X1

016406  

Unit Price

20
FLAT WASHER 6, 4X12X1

003056  

Unit Price

21
CABLE HARNESS SUPPORT BRACKET

643328  

Unit Price

22
SCREW W/ FLANGE

484123  

Unit Price

23
SPRING PLATE M5

248419  

Unit Price

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from PIAGGIO. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
When adding a part to your cart, be careful to order the required quantity. Please note that the unit price indicated is the price for each part number in quantity 1.
Our parts are original and brand new spare parts of PIAGGIO, to guarantee you quality and durable components. If you have any questions, we are here to help. Order your spare parts today and receive them directly at home!
