Rear wheel

SWINGING ARM FOR PIAGGIO CARNABY 4T E3 2008

Brakes pipes - Calipers

Item numbers
Swinging arm PIAGGIO PIAGGIO-SCOOTER 125 CARNABY 2008 Carnaby 4T E3
1
2
3
4
5
5
6
7
7
7
7
8
9
10
11
12
13
14
15
15
15
16
16
17
1
FRAME PIVOT PIN

AP8121191  

Unit Price

2
ENGINE PIVOT PIN

AP8121192  

Unit Price

3
SPACER

649122  

Unit Price

4
WASHER 10, 5X21X2*

AP8150020  

Unit Price

5
LOW SELF-LOCKING NUT M12*

AP8150432  

Unit Price

6
HEX SOCKET SCREW M12X90

AP8150554  

Unit Price

7
WASHER 12, 2X22X2

AP8152018  

Unit Price

8
SELF-LOCKING NUT

AP8152301  

Unit Price

9
SILENT-BLOCK

AP8161155  

Unit Price

10
SPACER

AP8121628  

Unit Price

11
COMPLETE SWINGING ARM

651256  

Contact
12
LOW SELF-LOCKING NUT M12*

AP8150432  

Unit Price

13
WASHER 12, 2X22X2

AP8152018  

Unit Price

14
CONNECTING ROD PIVOT PIN

AP8161019  

Unit Price

15
BUSH

598917  

Unit Price

16
ROLLER CAGE

600161  

Unit Price

17
SPACER

649123  

Contact
