FUEL TANK FOR PIAGGIO CARNABY 4T E3 2007

Helmet huosing - Undersaddle

Item numbers
Fuel tank PIAGGIO PIAGGIO-SCOOTER 125 CARNABY 2007 Carnaby 4T E3
1
2
2
3
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
18
19
1
FUEL TANK

653350  

Contact
2
SELF TAPPING SCREW L=20 MM

267958  

Unit Price

2
PHILLIPS SCREW, SWP M5X20

AP8152329  

Unit Price

3
HEX SCREW M6X22

031091  

Unit Price

3
METRIC SCREW M6X20

259830  

Unit Price

4
WASHER 6, 2X18X2

013950  

Unit Price

5
SPRING PLATE M6

254485  

Unit Price

6
COMPLETE COUPLING
COMPLETE FITTING

296817  

674592

Unit Price

7
GASKET

196868  

Unit Price

8
FASTENING CLAMP
CLIP OF FASTENING

577557  

879888

Unit Price

9
LEVEL GAUGE

CM025710  

Unit Price

10
PLUG

259832  

Unit Price

11
TANK COVER GASKET

258160  

Unit Price

12
FUEL COLLECTOR RUBBER

AP8144187  

Unit Price

13
2-WAY UNION

AP8101944  

Unit Price

14
JOINT "T"

297910  

Contact
15
TANK BREATHER PIPE Ø5X10 L.1060

CM001432  

Unit Price

16
HOSE CLAMP

847778  

Unit Price

17
VIS TCIC M5X10
CROSS SLOTTED SCREW WITH CYLINDER HEAD

018575  

1A003111

Unit Price

18
TANK BREATHER PIPE Ø5X10 L.1060

CM001432  

Unit Price

19
FLAT WASHER Ø5, 3XØ14X1

097733  

Unit Price

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from PIAGGIO. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.

Find on this page all the original spare parts relating to the Fuel tank of your PIAGGIO Carnaby 4T E3 of CARNABY. Let us know if you have any questions.

Genuine parts for PIAGGIO Carnaby 4T E3 2007

Engine Frame - Plastic parts - Coachwork Handlebars/Steering Suspensions - Wheels Braking system - Transmissions Electrical system

PIAGGIO Carnaby 4T E3 2007

Choose the exact model of your PIAGGIO CARNABY 125 to access the different categories of genuine spare parts

125 CARNABY 2007 Carnaby 4T E3

Carnaby 4T E3

PIAGGIO-SCOOTER CARNABY

Displacement: 125 cc
Year: 2007
