Displacement

Model

Year

Finish line

Parts catalogue

Parts diagram

Crankcase

CRANKCASE COVER - CRANKCASE COOLING FOR PIAGGIO FLY 4T 2011

Crankshaft

Item numbers
Crankcase cover - Crankcase cooling PIAGGIO PIAGGIO-SCOOTER 100 FLY 2011 Fly 4T
1
2
3
4
5
6
7
8
9
10
11
12
13
14
14
15
16
17
18
19
1
TRANSMISSION COVER

8431155  

Contact
2
BUSH Ø8XØ12X8

431860  

Unit Price

3
BEARING

82521R  

Unit Price

4
PIN D.9, 5 H=15
REFERENCE PLUG (D9.5, H=15)

239388  

B015956

Unit Price

5
BUSH

286209  

Unit Price

6
SCREW W/ FLANGE M6X30
FLANGED HEXAGONAL HEAD SCREW (M6X30)

289731  

B016792

Unit Price

7
HOSE CLAMP

271451  

Unit Price

8
HOSE CLAMP

844964  

Unit Price

9
CLAMP

482291  

1C006656

Unit Price

10
COOLING COVER
COVER

480076  

969804

Unit Price

11
GASKET

435251  

Unit Price

12
SCREW

435295  

Unit Price

13
BELLOWS

623012  

Contact
14
LOCK-STRAP L=180MM

145298  

Unit Price

15
PIPE

622267  

Unit Price

16
EXPANSION PLUG

199190  

Unit Price

17
SCREW M4, 2X13
SCREW

576189  

259349

Unit Price

18
HOSE

969899  

Unit Price

19
FILTER

969921  

Unit Price

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from PIAGGIO. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
When adding a part to your cart, be careful to order the required quantity. Please note that the unit price indicated is the price for each part number in quantity 1.
Our parts are original and brand new spare parts of PIAGGIO, to guarantee you quality and durable components. If you have any questions, we are here to help. Order your spare parts today and receive them directly at home!

Genuine parts for PIAGGIO Fly 4T 2011

Engine Frame - Plastic parts - Coachwork Handlebars/Steering Suspensions - Wheels Braking system - Transmissions Electrical system

PIAGGIO Fly 4T 2011

All the genuine spare parts for the PIAGGIO 2011

100 FLY 2011 Fly 4T

Fly 4T

PIAGGIO-SCOOTER FLY

Displacement: 100 cc
Year: 2011
