CRANKSHAFT ASSY-CYLINDER AND PISTON FOR GILERA RCR 50 2004

Drive shaft

Item numbers
Crankshaft assy-cylinder and piston GILERA GILERA-SCOOTER 50 RCR 2004 RCR 50
1
2
2
2
2
3
4
5
5
6
7
8
9
10
11
12
12
13
14
14
15
16
17
18
18
19
20
21
1
CYLINDER-PISTON, ASSY.

ODN00H05014121  

Contact
2
PISTON ASSY A-V/AL
PISTON-WRIST PIN ASSY.

ODN00H02542091  

8472625001

Unit Price

2
PISTON ASSY B-V/AL
PISTON-WRIST PIN ASSY.

ODN00H02552091  

8472625002

Unit Price

2
PISTON ASSY C-V/AL
PISTON-WRIST PIN ASSY.

ODN00H02562091  

8472625003

Unit Price

2
PISTON ASSY D-V/AL
PISTON-WRIST PIN ASSY.

ODN00H02572091  

8472625004

Unit Price

3
PISTON RING SET
PISTON RING

ODN00H02502111  

847006

Unit Price

4
PISTON PIN
PISTON PIN

ODN00H02502121  

847012

Unit Price

5
STOP RING
WRISTPIN RETAINING CLIP

ODN00H02501131  

847178

Unit Price

6
CYLINDER HEAD

ODN00H02512013  

Contact
7
GASKET

ODN00H02505021  

Contact
8
CYLINDER GASKET

ODN00H02500041  

Contact
9
DRIVE SHAFT

ODN00H02506141  

Contact
10
CRANKSHAFT PIN
CRANKSHAFT PIN

ODN00002025190  

00002025190

Unit Price

11
SEAL
SEAL

ODN00H02500301  

GU90402037

Unit Price

12
BEARING
BEARING

ODN00059220400  

Contact
13
SEAL
SEAL

ODN00E02500231  

GU90402037

Unit Price

14
WASHER

ODN00002225220  

Contact
15
NUT

ODN00008202730  

Contact
16
CON-ROD ASSY.

ODN00H05001011  

Contact
17
CAGE
CAGE

ODN00002125170  

847529

Unit Price

18
SEC. SCREW

ODN00G03001091  

Contact
19
SECURING WASHER, CYLINDER HEAD
SECURING WASHER, CYLINDER HEAD

ODN00003125280  

00003125280

Unit Price

20
THERMAL SWITCH

ODN00H02302441  

Contact
21
SPARK PLUG CHAMPION N3C
SPARK PLUG CHAMPION N3C

438005  

438076

Unit Price

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from GILERA. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
When adding a part to your cart, be careful to order the required quantity. Please note that the unit price indicated is the price for each part number in quantity 1.
Our parts are original and brand new spare parts of GILERA, to guarantee you quality and durable components. If you have any questions, we are here to help. Order your spare parts today and receive them directly at home!

Genuine parts for GILERA RCR 50 2004
