LIGHTS - ELECTRICAL SYSTEM FOR GILERA SMT 50 RACING 2011

Rear brake system

Item numbers

MAIN WIRING HARNESS
MAIN HARNESS

866993

2D000281

$253,67

Unit Price

FUSE 7, 5A

00H01001911

Contact

HOSE CLAMP

00D00900531

Contact

HOSE CLAMP

00D00900531

Contact

HOSE CLAMP 290X4, 8

00F00900531

$3,65

Unit Price

FLASHER UNIT

00H05700481

Contact

GUARD

00H02300961

Contact

SCREW

00011061300

$3,65

Unit Price

VOLTAGE REGULATOR

898891

$47,25

Unit Price

SCREW

00D05910081

Contact

SPRING PLATE M6
SPRING PLATE (M6)

00D01501371

254485

$3,30

Unit Price

WASHER D6

00D01200171

$3,65

Unit Price

SCREW 6MX100X12

00012061200

$3,65

Unit Price

HORN

00H01005311

Contact

TAILLIGHT

00H01009321

Contact

GROMMET

00008915020

$4,86

Unit Price

RING NUT

00D01500471

Contact

NUT M6100

00000023060

$2,95

Unit Price

WINDSHIELD

86420600W0B

Contact

HEADLIGHT WINDSHIELD BLACK

86420600W0N

$8,22

Unit Price

WINDSHIELD

86420600W5R

$7,72

Unit Price

FRONT DUST COVER RING
RETAINER 6X12, 35X0, 55 POLYTHENE

00H01500741

AP8120622

$3,65

Unit Price

WASHER

861239

Contact

FRONT HEADLIGHT SUPP.

866980

$26,83

Unit Price

SCREW W/ FLANGE M5X12
HEXAGON COCKET SCREWS M5X12

863408

Contact

NUT

00000023050

$3,65

Unit Price

CLIP M5

00G04401462

$7,68

Unit Price

RH CLAMP

866935

Contact

LH CLAMP

866936

Contact

SCREW
SCREW

00052062011

672380

$3,65

Unit Price

WASHER D6 DIN125 AZNB

00402060001

$3,65

Unit Price

NUT M6100

00000023060

$2,95

Unit Price

HEADLAMP

865385

$76,86

Unit Price

SCREW 3, 6X25

00011032501

$3,65

Unit Price

WASHER D4

00000031040

$2,95

Unit Price

SCREW

00H01003101

Contact

SPRING

00H02302501

Contact

CLIP M5

00G04401462

$7,68

Unit Price

LAMP 12V-35/35W
LAMP 12 V 35/35 W

00H01000131

219528

$13,37

Unit Price

LAMPHOLDER

00003710110

$6,38

Unit Price

SPRING

00003710120

$4,82

Unit Price

GUARD

00H05703141

$3,44

Unit Price

FRONT LEFT TURN INDICATOR

863008

Contact

RH FRONT TURN INDICATOR

863009

Contact

VIS M6X20 INOX
SCREW

862210

AP8224470

$3,30

Unit Price

WASHER D6 DIN125 AZNB

00402060001

$3,65

Unit Price

NUT M6100

00000023060

$2,95

Unit Price

LAMP RY10W 12V
LAMP RY10W 12V

00H01701011

AP8127489

$6,35

Unit Price

VIS M6X20 INOX
SCREW

862210

AP8224470

$3,30

Unit Price

DIODE-CONDENSER REGULATOR CABLE

2D000272

$24,20

Unit Price

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from GILERA. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.

Find on this page all the original spare parts relating to the Lights - Electrical system of your GILERA SMT 50 Racing of SMT. Let us know if you have any questions.
