Rear coverings for GILERA PIAGGIO VESPA X8

Rear coverings

1

PORTELLO BAULIERA

6202540090

$83,17 Unit Price incl. VAT

2

CONTROSPORTELLO BAULIERA

620758

$40,90 Unit Price incl. VAT

2

CONTROSPORTELLO

576816

$20,60 Unit Price incl. VAT

3

VITE AUTOF.CON TAGLIO A CROCE 3,5x13

297498

$0,08 Unit Price incl. VAT

4

Hinge

CM024002

Not Available

4

Hinge

CM024001

Not Available

5

DADO AUTOFR.TRIBL. M6 6H CH.10

219277

$0,16 Unit Price incl. VAT

6

RONDELLA PIANA METALLICA

013880

$0,08 Unit Price incl. VAT

7

RONDELLA PIANA METALLICA (12x4,2x1)

013763

$0,08 Unit Price incl. VAT

8

RONDELLA ELASTICA

016404

$0,42 Unit Price incl. VAT

9

PORTATARGA

584884

$2,30 Unit Price incl. VAT

10

DADO M4 - 6H

020104

$1,26 Unit Price incl. VAT

11

screw M4x14

018591

Not Available

12

VITE METRICA CON INT.A CROCE M6x16.

272836

$3,70 Unit Price incl. VAT

13

PROTEZIONE CERNIERA SX

CM024201

$2,41 Unit Price incl. VAT

13

PROTEZIONE CERNIERA DX

CM024202

$2,41 Unit Price incl. VAT

14

TARGHETTA "PIAGGIO"

621312

$3,17 Unit Price incl. VAT

15

PERNO PULSANTE

621097

$1,34 Unit Price incl. VAT

16

SEDE PERNO PULSANTE

621098

$1,34 Unit Price incl. VAT

17

MOLLA

621099

$0,34 Unit Price incl. VAT

18

PARASPRUZZI

620256000P

$12,53 Unit Price incl. VAT

19

VITE METRICA CON CODOLO

575249

$0,66 Unit Price incl. VAT

20

PIASTRINA ELASTICA M6

254485

$0,34 Unit Price incl. VAT

21

PROLUNGA PER PORTATARGA

584877

$1,43 Unit Price incl. VAT

22

VITE AUTOFILETTANTE PER MATERIE PLAST.

268596

$0,08 Unit Price incl. VAT

23

Spring

621127

$5,38 Unit Price incl. VAT

24

GUARNIZ. BAULIERA POST

561449

$24,14 Unit Price incl. VAT

Find the detailed Rear coverings GILERA PIAGGIO VESPA diagram on this page. This exploded view allows you to identify the various components you need to maintain your machine and quickly find their original GILERA PIAGGIO VESPA part number.

The diagrams are not contractually binding. If you have any doubts, our professionals are available to answer your questions. When adding a part to your cart, make sure to order the desired quantity. The unit price shown is the price for each reference at a quantity of 1.
