1
Engine displacement
125
2
Model
SFERA
3
Year
0
4
Trim
Sfera RST
5
Parts Catalog
Front brake cylinder
6
Parts Diagram
Parts Catalog
Transmissions
by
Electrical devices
Front brake cylinder
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
1
Spring plate
184142
Not Available
2
Cover
498431
$8,31 Unit Price incl. VAT
3
screw 4,2x19
258249
$0,09 Unit Price incl. VAT
4
Spring clamp
104296
$0,38 Unit Price incl. VAT
5
Pin
271357
Not Available
6
Lock-strap L=180mm
145298
$0,08 Unit Price incl. VAT
7
Oil pipe screw M10x18
265451
$9,25 Unit Price incl. VAT
8
pipe
274917
Not Available
9
Hex screw M6x22
031091
$0,17 Unit Price incl. VAT
10
Spring washer 6,4x11,8x1
016406
$0,34 Unit Price incl. VAT
11
Flat washer 6,4x12x1
003056
$0,08 Unit Price incl. VAT
12
Transmission
273670
Not Available
13
pipe
152181
Not Available
14
Gasket
127927
$0,25 Unit Price incl. VAT
15
Brake oil tank
274598
$9,00 Unit Price incl. VAT
16
Pump
271019
Not Available
17
Spring washer
006964
$0,67 Unit Price incl. VAT
The diagrams are provided for reference only. If in doubt, our specialists are available to answer your questions. When adding a part to your cart, please make sure to select the desired quantity. The unit price shown is the price for one unit of each part number.
