Componenti motore elettrico FOR Vespa Primavera Elettrica 45 Km/h FROM 2023

Componenti motore elettrico

1

Complete transmission casing

1A022078

Not Available

2

Locating dowel Ã˜11x10

478115

$0,24 Unit Price incl. VAT

3

Roulement radial 15x42x13

B014367

$13,50 Unit Price incl. VAT

4

Roulement radial 20x47x14

B014368

$13,50 Unit Price incl. VAT

5

Circlip 25x26.9x1.2

000674

Not Available

6

Tôle tenue câbles stator

1A010645

$4,62 Unit Price incl. VAT

7

Screw w/ flange M5x16

830061

$0,34 Unit Price incl. VAT

8

Gasket ring 20-32-7

82878R

$10,25 Unit Price incl. VAT

9

Roulement radial 17x40x12

880682

$13,50 Unit Price incl. VAT

10

Circlip

825667

$0,42 Unit Price incl. VAT

11

Tuyau

1A010657

$4,25 Unit Price incl. VAT

12

Wiring clip

1D001143

$0,34 Unit Price incl. VAT

13

Stator du moteur électrique

1P000079

Not Available

14

Rotor du moteur électrique

1A015957

$515,95 Unit Price incl. VAT

15

Belleville spring

875970

$5,67 Unit Price incl. VAT

16

Nut

021216

$2,70 Unit Price incl. VAT

17

Rotary speed sensor

1A010748

$4,00 Unit Price incl. VAT

18

Split pin

012770

Not Available

19

Complete oil level dipstick

832130

$2,94 Unit Price incl. VAT

20

Gasket ring 14,43x9,19x2,62

827085

$2,99 Unit Price incl. VAT

The diagrams are provided for reference only. If in doubt, our specialists are available to answer your questions. When adding a part to your cart, please make sure to select the desired quantity. The unit price shown is the price for one unit of each part number.
