1
Engine displacement
150
2
Model
FLY
3
Year
0
4
Trim
Fly
5
Parts Catalog
Rear wheel shaft
6
Parts Diagram
Parts Catalog
Rear mudguard
by
Handlebars component parts
Rear wheel shaft
1
2
3
4
5
6
6
7
8
10
11
13
14
15
1
Driven pulley shaft
4858795
Not Available
2
Wheel axle
827090
Not Available
3
Gasket ring
82541R
Not Available
4
Snap ring
006652
$0,76 Unit Price incl. VAT
5
Cover
487115
$0,29 Unit Price incl. VAT
6
Complete reducer cover
8460245
Not Available
7
Screw w/ flange M8x45
487211
$0,29 Unit Price incl. VAT
8
Radial bearing 25x52x15
478984
$14,08 Unit Price incl. VAT
9
Transmission shaft
4859955
$86,90 Unit Price incl. VAT
10
Breather pipe
844669
$4,89 Unit Price incl. VAT
11
Washer 8.2x12x1
485703
$0,16 Unit Price incl. VAT
12
Gasket
487383
Not Available
13
Radial ball bearing 15x42x13
485912
Not Available
14
Hose clamp
827277
$3,65 Unit Price incl. VAT
15
Hex socket screw M8x12
269755
$0,34 Unit Price incl. VAT

Find the detailed :label GILERA PIAGGIO VESPA diagram on this page. This exploded view allows you to identify the various components you need to maintain your machine and quickly find their original GILERA PIAGGIO VESPA part number.


The diagrams are not contractually binding. If you have any doubts, our professionals are available to answer your questions. When adding a part to your cart, make sure to order the desired quantity. The unit price shown is the price for each reference at a quantity of 1.
